| Brand |
X-SECURITY |
| Inputs for IP cameras |
LAN port up to 32 channels |
| PoE |
16 PoE ports IEEE802.3af/at (8ePoE) |
| IP compatible cameras |
X-SECURITY (proprietary protocol), ONVIF |
| Video outputs |
1 HDMI 4K,1 HDMI FullHD, 1 VGA |
| Bidirectional audio |
1 input, 1 output, RCA |
| Video compression format |
Smart H.265+ / H.265 / Smart H.264+/ H.264 |
| Display resolution |
3840× 2160, 1920× 1080, 1280× 1024, 1280× 720, 1024× 768 |
| Total bandwidth |
320 Mbps |
| Recording resolution |
12Mp, 8Mp, 6Mp, 5Mp, 3Mp, 1080P, 1.3Mp, 720P ... |
| Simultaneous multifunction |
Pentaplex: Live, Recording, Playback, Backup and Remote Access |
| Alarms |
4 Inputs / 2 Relay NO/NC |
| Recording method |
Manual, programmed, motion detection, alarm |
| Artificial intelligence |
Facial recognition up to 4Ch (16CH with facial detection camera) or up to 16Ch recognition of humans and vehicles in VCA rules |
| Backup |
USB (Memory, HDD, CD-RW, DVR-RW) / Network / SATA |
| Internal memory |
4 SATA HDD 3.5" of up to 10 TB (not included) |
| Communication |
3xUSB (Mouse & backup) / 1 RJ45 10/100/1000M (Ethernet) |
| Remote access |
Web browser (ActiveX), mobile phone application or PSS software |
| Power |
AC 100~240V 50~60 Hz / PoE IEEE802.3af/at |
| Dimensions |
53 (H) x 328 (W) x 375 (D) mm / 2.6 Kg (without HDD) |
