| Brand |
X-Security |
| Image sensor |
1/1.8" STARVIS™ CMOS |
| Resolution |
4K (3840 x 2160); 1080P (1920 × 1080); 1.3M (1280x 960); 720P (1280 × 720); D1 (704 × 576); CIF (352 ×288) |
| Compression |
H.265+/H.265/H.264+/H.264/MJPEG (sub stream) |
| Main Stream rate |
8M / 1080P / 1.3M / 720P (1–25/30 fps) |
| Extra Stream rate |
2º: D1 / CIF (1–25/30 fps), 3º:1080P / 1.3M / 720P / D1 / CIF (1–25/30 fps) |
| Bitrate |
H.265/H.264: 32 kbps–8192 kbps |
| Lens |
Varifocal 5.4 ~ 135 mm (Optical zoom 25X) Auto Iris, Auto Focus |
| Digital zoom |
x16 |
| Image improvements |
WDR (120dB),2D/ 3DNR, HLC, BLC, ATW, AGC, Privacy Mask |
| Minimum illumination |
0.005 Lux (Colour) / 0.0005 Lux (B/W) |
| Infrared lighting |
0 Lux @ 150m range |
| Day / Night |
Removable mechanical ICR filter |
| Intelligent functions |
Autotracking, face detection, line crossing, abandoned object, intrusion, false alarm filtering for humans and vehicles |
| Audio |
1 input (Line In) / 1 output (Line Out) |
| Alarms |
2 inputs / 1 relay |
| Network interface |
Ethernet 10/100 BaseT |
| Remote access |
WEB interface, CMS software, mobile application and NVR |
| Memory |
Slot for Micro SD card (Max 256 GB) |
| Pan/Tilt Range |
Horizontal: 0°~360°, Vertical: -15°~90° auto flip 180° |
| Manual speed |
Horizontal: 0.1°~300° /s, Vertical: 0.1°~200° /s |
| Speed between Presets |
Horizontal: 400° /s, Vertical: 300° /s |
| Preset positions |
300, 5 auto pattern, 8 auto tour, 5 auto scan |
| Communication |
DH-SD, ONVIF Compatible |
| Power |
AC 24 V / 3 A , PoE+(802.3at) |
| Degree of protection |
Weatherproof IP67, Anti-vandal IK10 |
| Temp. operation |
-40º C ~ +70º C |
| Dimensions |
332 mm (H) x 190 (Ø) mm |
| Weight |
4700 g |
