| Brand |
X-Security |
| Image sensor |
1/2.8” Sony© Starvis CMOS |
| Resolution |
1080p(1920x1080), 1.3M(1280x960), 720p(1280x720), D1(704x576), CIF(352x288) |
| Compression |
H.265+ / H.265 / H264+ / H.264 |
| Main Stream rate |
1080p/1.3M/720p(1~50fps) |
| Extra Stream rate |
2º:D1/CIF (1 ~ 25 FPS), 3º:1080p/1.3M/720p/D1/CIF (1 ~ 25 FPS) |
| Bitrate |
448 Kbps ~ 8192 Kbps |
| Lens |
4.8 ~ 120 mm (Optical Zoom 30X) Auto Focus |
| Digital zoom |
16 X |
| Image improvements |
WDR (120dB), 3DNR, HLC, BLC, AGC, Privacy Mask, Motion Detection, ROI, Flip, Defog |
| Intelligent detection |
Line crossing, Perimeter, Lost/Abandoned object, Face detection |
| Minimum illumination |
0.005 Lux (colour) / 0.0005 Lux (B/N) |
| Day / Night |
Removable mechanical ICR filter |
| Network interface |
Ethernet 10/100 BaseT |
| Remote access |
WEB interface, CMS software, mobile application and NVR |
| Memory |
Slot for Micro SD card (Max 128 GB) |
| Pan/Tilt Range |
Horizontal: 0°~360°, Vertical: 0°~90°, Auto flip 180° |
| Manual speed |
Horizontal: 0.1°~350° /s, Vertical: 0.1°~250° /s |
| Speed between Presets |
Horizontal: 500° /s, Vertical: 500° /s |
| Preset positions |
300, 5 auto pattern, 8 auto tour, auto pan, auto scan |
| Communication |
DH-SD, ONVIF Compatible |
| Alarms |
2 inputs / 1 relay NO/NC |
| Audio |
1 input (Line In) / 1 output (Line Out) |
| Power |
AC 24 V / 1.5 A , PoE+ IEEE802.3at |
| Degree of protection |
Vandal proof IK10 |
| Temp. operation |
-30º C ~ +60º C |
| Dimensions |
177 mm (H) x 198 (Ø) mm |
| Weight |
3700 g |
