| Brand |
X-Security |
| Image sensor |
1/2.8” Sony Starvis CMOS Starlight |
| Resolution |
1080p(1920x1080), 720p(1280x720), 1,3Mpx (1280x960), D1(704x576), CIF(352x288) |
| Compression |
H.265 / H264 / MJPEG (video), G711a / G771u / AAC (audio) |
| Main Stream rate |
1080p / 720p / 1,3 Mpx (1~50fps) |
| Extra Stream rate |
2º:D1/CIF, 3º:1080p/720p/1,3Mpx/D1/CIF (1 ~ 25 FPS) |
| Bitrate |
448 Kbps ~ 8 Mbps |
| Lens |
Varifocal 4.8 ~ 120 mm (Optical zoom 25X) Auto Iris, Auto Focus |
| Digital zoom |
16 X |
| Image improvements |
WDR (120dB),2D/ 3DNR, HLC, BLC, ATW, AGC, Privacy Mask |
| Minimum illumination |
0.005 Lux (colour) / 0.0005 Lux (B/N) |
| Day / Night |
Removable mechanical ICR filter |
| Network interface |
Ethernet 10/100 BaseT |
| Remote access |
WEB interface, CMS software, mobile application and NVR |
| Memory |
Slot for Micro SD card (Max 128 GB) |
| Pan/Tilt Range |
Horizontal: 0°~360°, Vertical: 0°~90° auto flip 180° |
| Manual speed |
Horizontal: 0.1°~350° /s, Vertical: 0.1°~250° /s |
| Speed between Presets |
Horizontal: 500° /s, Vertical: 500° /s |
| Preset positions |
300, 5 auto pattern, 8 auto tour, 5 auto scan |
| Auto Tracking |
Simple, multiple and panoramic scene |
| IVS functions |
Tripwire, area intrusion, perimeter protection, abandoned/lost object detection, illegal stopping, rapid movements, etc.. |
| Communication |
DH-SD, ONVIF Compatible |
| Alarms |
2 inputs / 1 relay NO/NC |
| Audio |
1 input (Line In) / 1 output (Line Out) |
| Power |
24VAC / 1,5A, PoE+(802.3at) |
| Degree of protection |
Weatherproof IP67, Anti-vandal IK10 |
| Temp. operation |
-40º C ~ +60º C |
| Dimensions |
253 mm (H) x 186 (Ø) mm |
| Weight |
2500 g |
