| Brand |
X-Security |
| Image sensor |
1/2.7” Progressive Scan CMOS |
| Resolution |
1080p(1920x1080), 720p(1280x720), D1(704x576), CIF(352x288) |
| Compression |
H.264+ / H.264 / MJPEG |
| Main Stream rate |
1080p (1~25FPS) / 720p(1~50FPS) |
| Extra Stream rate |
2º: D1/CIF (1 ~ 25 FPS), 3º: 720p/D1/CIF (1 ~ 25 FPS) |
| Bitrate |
448 Kbps ~ 8192 Kbps |
| Lens |
5.1 ~ 61.2 mm (Optical Zoom 12X) Auto Focus |
| Digital zoom |
16 X |
| Image improvements |
WDR (120dB), 3DNR, HLC, BLC, AGC, Privacy Mask, Motion Detection |
| Intelligent detection |
Tripwire, Perimeter, Lost/Abandoned object |
| Minimum illumination |
0.05 Lux (colour) / 0.005 Lux (B/N) |
| Day / Night |
Removable mechanical ICR filter |
| Network interface |
Ethernet 10/100 BaseT |
| Remote access |
WEB interface, CMS software, mobile application and NVR |
| Memory |
Slot for Micro SD card (Max 128 GB) |
| Pan/Tilt Range |
Horizontal: 0°~360°, Vertical: |
| Manual speed |
Horizontal: 0.1°~300° /s, Vertical: 0.1°~1200° /s |
| Speed between Presets |
Horizontal: 300° /s, Vertical: 200° /s |
| Preset positions |
300, 5 auto pattern, 8 auto tour, auto pan, 5 auto scan |
| Communication |
DH-SD, ONVIF Compatible |
| Alarms |
2 inputs / 1 relay NO/NC |
| Audio |
1 input (Line In) / 1 output (Line Out) |
| Power |
AC 24 V / 1.5 A , PoE+ IEEE802.3at |
| Degree of protection |
Interior, Anti-vandalism IK10 |
| Temp. operation |
-20º C ~ +60º C |
| Dimensions |
158 mm (H) x 198 (Ø) mm |
| Weight |
2300 g |
