| Brand |
X-Security |
| Image sensor |
1/2.8" STARVIS™ CMOS |
| Resolution |
4M(2560x1440), 3M(2048 x 1536), 1080P(1920x1080), 1.3M(1280x960), 720P(1280×720),D1(704×576/704×480),CIF(352×288/352×240) |
| Compression |
H.265+/H.265/H.264+/H.264/MJPEG (sub stream) |
| Main Stream rate |
4MP/3MP/1080P/1.3MP/720P (1~25fps) |
| Extra Stream rate |
2º:D1/CIF (1~25fps), 3º:1080P/1.3M/720P/D1/CIF (1~25fps) |
| Bitrate |
H.265/H.264: 3K~20480Kbps |
| Lens |
Varifocal 4.8 ~ 120 mm (Optical zoom 25X) Auto Iris, Auto Focus |
| Digital zoom |
16 X |
| Image improvements |
WDR (120dB),2D/ 3DNR, HLC, BLC, ATW, AGC, Privacy Mask |
| Minimum illumination |
0.005 Lux (Colour) |
| Infrared lighting |
0 Lux @ 100m range |
| Day / Night |
Removable mechanical ICR filter |
| Network interface |
Ethernet 10/100 BaseT |
| Remote access |
WEB interface, CMS software, mobile application and NVR |
| Memory |
Slot for Micro SD card (Max 256 GB) |
| Pan/Tilt Range |
Horizontal: 0°~360°, Vertical: -15°~90° auto flip 180° |
| Manual speed |
Horizontal: 0.1°~200° /s, Vertical: 0.1°~120° /s |
| Speed between Presets |
Horizontal: 240° /s, Vertical: 200° /s |
| Preset positions |
300, 5 auto pattern, 8 auto tour, 5 auto scan |
| Communication |
DH-SD, ONVIF Compatible |
| Alarms |
2 inputs / 1 relay NO/NC |
| Audio |
1 input (Line In) / 1 output (Line Out) |
| Power |
DC 12 V / 3 A, PoE+(802.3at) |
| Degree of protection |
Weatherproof IP66 |
| Temp. operation |
-40º C ~ +70º C |
| Dimensions |
295 mm (H) x 160 (Ø) mm |
| Weight |
3000 g |
