| Brand |
X-Security |
| Image sensor |
1/2.8" Sony© Starvis CMOS Starlight |
| Resolution |
1080P(1920x1080) / 1.3M(1280x960) / 720P(1280x720) / D1(704x576/704x480) / CIF(352x288/352x240) |
| Compression |
H.265+/H.265/H.264+/H.264 (video), G.711a/G.711Mu/AAC/G.722 / G.726/G.729/ MPEG2-L2 (audio) |
| Main Stream rate |
1080P/1.3M/720P(1~50/60fps) |
| Extra Stream rate |
2º: D1/CIF(1 ~ 25/30fps), 3º: 1080P/1.3M/720P/D1/CIF (1~25/30fps) |
| Bitrate |
256 Kbps ~ 8 Mbps |
| Lens |
4.5~180mm Vari-focal (40X) Optical zoom, Auto Iris, Auto Focus |
| Digital zoom |
16 X |
| Image improvements |
Ultra WDR (140dB), 2D/ 3DNR, HLC, BLC, ATW, AGC, MD, ROI, EIS, Privacy Mask |
| Intelligent functions |
Face and motion detection, heat mapping, line crossing, abandoned object, intrusion, ROI |
| Minimum illumination |
0.005 Lux (colour) / 0 Lux (B/N) IR LEDs (300m) |
| Day / Night |
Removable mechanical ICR filter |
| Network interface |
Ethernet 10/100 BaseT/TX |
| Remote access |
WEB interface, CMS software, mobile application and NVR |
| Memory |
Slot for Micro SD card (Max 128 GB) |
| Pan/Tilt Range |
Horizontal: 0°~360°, Vertical: 0°~360° |
| Manual speed |
Horizontal: 0.1°~120° /s, Vertical: 0.1°~60° /s |
| Speed between Presets |
Horizontal: 120° /s, Vertical: 60° /s |
| Preset positions |
300, 5 auto pattern, 8 tour, auto pan, auto scan |
| Communication |
DH-SD, RS485 |
| Alarms |
7 inputs / 2 relay NO/NC |
| Audio |
1 input (Line In) / 1 output (Line Out) |
| Power |
24VAC / 5 A, Hi-PoE |
| Degree of protection |
Weatherproof IP68, corrosion-resistant |
| Temp. operation |
-40º C ~ 70º C |
| Dimensions |
234 (Top base) x 205 (Bottom base) x 405.5 (Height) mm |
| Weight |
9.8 Kg |
