| Brand |
Uniview |
| Range |
Easy |
| Video format |
HDTVI / HDCVI / AHD / CVBS / IP |
| Video inputs |
8 CH BNC |
| Hybrid configuration |
4 IP channels (IP only up to 12 channels) substituting all BNC channels |
| Video outputs |
1 HDMI, 1 VGA (1920x1080p) |
| Audio inputs |
1 Channel RCA |
| Audio outputs |
1 Channel RCA |
| Bidirectional audio |
Reusing the audio input/output |
| Alarms |
4 inputs/ 1 outputs |
| Maximum IP recording resolution |
4K |
| Analog cameras supported |
TVI / AHD: 8MP@12FPS (canal1-canal4); 5MP@20FPS; 4MP@30FPS; 3MP@30FPS (canal1-canal4); 1080P@30FPS; 720P@60FPS
CVI: 8MP@15FPS(canal1-canal4); 4MP@30FPS; 1080P@30FPS; 720P@60FPS
*For the correct live display, the combination of resolution and FPS
of the connected analog cameras must be equal to or lower than the specifications indicated, but in no case higher than the specifications indicated. |
| Main Stream recording encoding |
8MPLite@8FPS (canal1-canal4); 5MPLite@12fps; 4MPLite@15FPS; 3MP@15FPS(canal1-canal4); 2MP@15FPS; 720P@30FPS |
| Extra Stream recording encoding |
D1@30FPS |
| Recording method |
Manual, programmed, motion detection |
| Internal memory |
1 SATA HDD 3.5" of up to 8 TB (not included) |
| External interface |
2 x USB (Mouse and backup) / RJ45 10M/100M/1000M (Ethernet) / RS485 |
| Remote access |
Web Browser, CMS Software (EZStation), Smartphone (EZView/EZLive) |
| Power |
DC 12V / 12W |
| Dimensions / Weight |
47 (H) x 260 (W) x 226 (D) mm / 1.1 kg |
