Brand |
Safire Smart |
Range |
B1 with Night Colour |
Image sensor |
1/3" Progressive Scan CMOS |
Maximum resolution |
4 Megapixel (2560x1440) |
Minimum illumination |
Color: 0.03 Lux @(F1.6, AGC ON) |
White LED range |
20 m |
Day/Night |
Night Color, color image 24/h |
Electronic Shutter |
1/3~1/100.000 s |
Main Stream rate |
25 FPS (4Mpx, 3Mpx, 1080P, 720P) |
Extra Stream rate |
25 FPS (720P, D1, CIF) |
Third Stream Rate |
25 FPS (D1, 480x240, CIF) |
Compression |
H.265+, H.265, H.264+, H.264 |
Bitrate |
64 Kbps ~ 8 Mbps |
Lens |
2.8 mm |
Viewing Angle (FOV) |
H: 95.5°, V: 52°, D: 112.3° |
Range performance |
59 m (D), 24 m (O), 12 m (R), 6 m (I) |
Image improvements |
DWDR, BLC, HLC, 3D-DNR, AWB, ROI, ROI, Mirror function, Privacy masking, ROI |
Motion Detection |
Yes |
Smart Features |
VCA Rules: Area intrusion, Line crossing, abandoned object, removed object, Video exceptions (scene change, video loss), |
Audio |
Integrated microphone |
Audio Compression |
G711A / U |
Network interface |
Ethernet 10 / 100M BaseT |
Remote access |
Web Browser, Smartphone App Safire Smart, PC Software Safire Smart VMS |
Interoperability |
ONVIF |
Power |
DC 12 V / 458 mA / 5.5 W max. / IEEE802.3af PoE |
Degree of protection |
Weatherproof IP67 |
Material |
Plastic |
Temp. operation |
-20º C ~ +55º C |
Dimensions |
73.70 (H) x 74.70 (W) x 161.5 (D) mm |
Weight |
240 g |
