| Brand |
Safire Smart |
| Range |
B2 |
| Inputs for IP cameras |
32CH IP |
| IP compatible cameras |
Safire Smart (native protocol), ONVIF |
| Bidirectional audio |
1 input / 1 RCA output |
| Main Stream recording |
12MP/8MP/6MP/5MP/4MP/3MP/1080P/1280×1024/960P/720P/
960H/D1/CIF |
| Decoding capacity |
1CH 12Mpx @ 20FPS
4CH 1080P @ 30FPS |
| Video compression format |
H.265+ / H.265 / H.264+ / H.264 |
| Audio Compression |
G.711(U/A) |
| Total bandwidth |
160 Mbps downstream / 160 Mbps upstream |
| Video outputs |
1 HDMI 4K / 1 HDMI FullHD / 1 VGA |
| Display resolution |
HDMI 1: 3840x2160, 1920x1080, 1280x1024, 1024x768
HDMI 2: 1920x1080, 1280x1024, 1024x768
VGA: 1920x1080, 1280x1024, 1024x768
*HDMI 1 and HDMI 2 separate
*HDMI 1 and VGA simultaneous |
| Simultaneous multifunction |
Pentaplex: Live, Recording, Playback, Backup and Remote Access |
| Multi-Screen |
Main output: 1 / 4 / 6 / 8 / 9 / 13 / 16 / 25 / 36 (Live View)
Secondary output: 1 / 4 / 6 / 8 / 9 (Live view) |
| Recording method |
Manual, programmed, motion detection, smart events, alarm input, POS |
| POS Function |
Si |
| Perimeter Protection |
Need to use Safire Smart 4I1 or 8I2 cameras
Artificial Intelligence based on the classification of humans, vehicles and two-wheeled vehicles on:
- Area intrusion
- Line crossover
- Region entry
- Exit region
Detailed searches for intelligent events |
| Facial recognition |
Face detection with Safire Smart cameras 4I1 or 8I2 up to 32CH (All channels)
Face detection by the NVR itself with any camera up to 2CH
Facial recognition up to 6CH max
Computation of up to 18 images / second
32 Libraries and up to 10000 face images
Image searches via recorder, APP and PC software
Face tracking on map or plan
Statistical information on face results by day, week, month or customized period |
| Video metadata |
Need to use Safire Smart 4I1 or 8I2 cameras
Human and vehicle feature extraction
For humans: Can extract up to 13 features (glasses, color of clothes, etc.)
For vehicles: can extract up to 5características (color, type, etc.) |
| License plate recognition |
Yes (Safire Smart license plate camera required) |
| Dewarping |
Supports Fisheye camera dewarping via web and APP |
| Alarms |
16 Inputs / 4 Outputs |
| External Backup |
USB memory / HDD USB / CD-RW USB / DVR-RW USB |
| Internal memory |
2x 3.5" HDD SATA3.0 up to 10 TB (not included) |
| Communication |
1 x USB 3.0 / 2 x USB 2.0 / 2 x RJ45 10/100/1000M (Ethernet) / RS485 |
| Remote access |
Web Browser, Safire Smartphone App and PC Software Safire Smart VMS |
| Power |
DC 12V / 4A, ≤ 20W (Without hard disk) |
| Operating temperature |
-10ºC ~50ºC, Humidity 10~90% |
| Dimensions / Weight |
48.1 (H) x 380 (W) x 268 (D) mm / 1.18 Kg |
