| IP Video Input |
64-ch |
| HDMI Output |
4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 ×1440)/60Hz, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz,<br/>1280 × 720/60Hz, 1024 × 768/60Hz |
| VGA Output |
2K (2560 × 1440)/60Hz, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| Incoming Bandwidth |
320 Mbps |
| Audio Output |
2-ch, RCA (2.0Vp-p, 1 KΩ) |
| Two-Way Audio |
1-ch, RCA (2.0 Vp-p, 1kΩ) |
| Decoding Format |
H.265/H.265+/H.264/H.264+/MPEG4 |
| Decoding Capability |
2-ch @ 12 MP (20fps) / 4-ch @ 8 MP (25fps) / 8-ch @ 4MP (30fps) / 16-ch @ 1080p (30fps) |
| Synchronous playback |
16-ch |
| Recording Resolution |
12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF<br/>/2CIF/CIF/QCIF |
| Network Protocol |
TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS |
| Network Interface |
2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
| RAID Type |
RAID0, RAID1, RAID5, RAID6, RAID10 |
| SATA |
8 SATA interfaces |
| Capacity |
Up to 10 TB capacity for each HDD |
| USB Interface |
Front panel: 1 × USB 2.0; Rear panel: 1 × USB 3.0 |
| Alarm In/Out |
16/4 |
| Power Supply |
100 to 240 VAC, 50 to 60 Hz |
| Consumption |
≤ 30 W |
| Working Temperature |
-10 °C to 55 °C (14 °F to 131 °F) |
| Working Humidity |
10 to 90 % |
| Dimension (W × D × H) |
445 × 470 ×90 mm (17.5"× 18.5" × 3.5") | ≤ 8 kg (17.6 lb) |
