| Brand |
Safire |
| Inputs for IP cameras |
LAN port up to 16 channels |
| IP compatible cameras |
SAFIRE (native protocol), ONVIF |
| Video outputs |
1 HDMI 4K, 1 HDMI 1080P, 1 VGA, 1 CVBS BNC (independent) |
| Video compression format |
H.265+ / H.265 / H.264+ / H.264 / MPEG4 |
| Main display resolution |
3840x2160 (30 Hz), 2560x1440, 1920x1080, 1280x1024, 1280x720, 1024x768 (60 Hz) |
| Auxiliary display resolution |
1920x1080, 1600x1200, 1280x1024, 1280x720, 1024x768 (60 Hz) |
| Recording resolution |
12MP/8MP/6MP/5MP/3MP/1080P /UXGA /720P /VGA /4CIF /DCIF /2CIF /CIF /QCI |
| Audio inputs |
1 RCA input |
| Audio outputs |
1 RCA output |
| Bidirectional audio |
Reusing the audio input |
| Simultaneous multifunction |
Pentaplex: Live, Recording, Playback, Backup and Remote Access |
| VCA Rules |
VCA: Crossing Line | Intrusion in area |
| Smart Features |
TrueSense: False alarm filter for vehicles and people up to 4CH (Maximum resolution allowed): IP cameras up to 4Mpx) |
| POS Function |
Supports (Integration and coordination of points of sale tickets with the IP video recorder) |
| Alarms |
16 inputs / 4 relay |
| Total bandwidth |
256 Mbps downstream / 200 Mbps upstream |
| Recording method |
Manual, programmed, motion detection, alarm |
| Backup |
USB memory / HDD USB / CD-RW USB / DVR-RW USB |
| Internal memory |
4 SATA HDD 3.5" of up to 8 TB (not included) |
| Communication |
1 x USB 3.0 / 1 x USB 2.0 / 1 x RJ45 10/100/1000Mbps (Ethernet) |
| Remote access |
Web browser, Safire Control Center Smartphone App and PC Software |
| Power |
AC 100~240 V, 50Hz, <30W |
| Operating temperature |
-10° ~ +55° C |
| Rack mountable |
1.5U |
| Dimensions / Weight |
71 (H) x 445 (W) x 400 (D) mm / 5 Kg |
