| Facial Detection and Analytics |
Search by picture is supported |
| Face Picture Library |
32 libraries；100, 000 pictures |
| Face Picture Comparison |
16-ch face pictures comparison alarm,<br/>Alarm linkage actions: recording, audio warning, notify surveillance center, send email<br/> |
| Human/Vehicle Analysis |
Up to 16-ch 2 MP (H.264/H.265) video analysis for human and vehicle recognition to reduce false alarm |
| IP Video Input |
16-ch；Up to 12 MP resolution |
| HDMI 1 Output |
4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| HDMI 2 Output |
1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| VGA Output |
1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz, HDMI1/VGA Simultaneous Output |
| CVBS Output |
1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480 |
| Incoming Bandwidth |
320 Mbps |
| Outgoing Bandwidth |
256 Mbps |
| Audio Output |
1-ch, RCA (Linear, 1 KΩ) |
| Two-Way Audio |
1-ch, RCA (2.0 Vp-p, 1 k Ω) |
| Decoding Format |
H.265/H.265+/H.264/H.264+/MPEG4 |
| Decoding Capability |
16-ch @ 1080p |
| Synchronous playback |
16-ch |
| Recording Resolution |
12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF/2CIF/CIF/QCIF |
| Network Protocol |
TCP/IP, DHCP, Safire Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS |
| Remote Connection |
128 |
| Network Interface |
2 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interfaces |
| SATA |
4 SATA interfaces |
| eSATA |
1 eSATA interface |
| Capacity |
Up to 10 TB capacity for each HDD |
| Serial Interface |
RS-485 (half-duplex), RS-232, Keyboard |
| USB Interface |
Front panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0 |
| Alarm In/Out |
16/8 |
| Power Supply |
≤ 80 W |
| Consumption |
≤ 30 W |
| Working Temperature |
-10 °C to 55 °C (14 °F to 131 °F) |
| Working Humidity |
10 to 90 % |
| Chassis |
19-inch rack-mounted 1.5U chassis |
| Dimension (W × D × H) |
445 × 400 ×71 mm ( 17.5"× 15.7" × 2.8") | ≤ 5 kg (11 lb) |
