| IP Video Input |
16-ch,Up to 12 MP resolution |
| HDMI Output |
4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| VGA Output |
1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| CVBS Output |
1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480 |
| Incoming Bandwidth |
160 Mbps,256 Mbps |
| Audio Output |
1-ch, RCA (Linear, 1 KΩ) |
| Two-Way Audio |
1-ch, RCA (2.0 Vp-p, 1 k Ω) |
| Decoding Format |
H.265/ H.265+/H.264/H.264+/MPEG4 |
| Decoding Capability |
2-ch @ 12 MP (20fps) / 4-ch @ 8 MP (25fps) / 8-ch @ 4MP (30fps) / 16-ch @ 1080p (30fps) |
| Synchronous playback |
16-ch |
| Recording Resolution |
12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF/ 2CIF/CIF/QCIF |
| Network Protocol |
TCP/IP, DHCP, Safire Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS |
| Remote Connection |
128 |
| Network Interface |
1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
| Interface |
N/A |
| RAID Type |
No |
| SATA |
2 SATA interfaces for 2HDDs |
| Capacity |
Up to 8TB capacity for each HDD |
| USB Interface |
Front panel: 1 × USB 2.0; Rear panel: 1 × USB 3.0 |
| Alarm In/Out |
4/1 |
| Power Supply |
12 VDC,≤40 W |
| Consumption |
≤15 W |
| Working Temperature |
-10 °C to 55 °C (14 °F to 131 °F) |
| Working Humidity |
10 to 90 % |
| Dimension (W × D × H) |
385 × 315× 52 mm (15.2" × 12.4" × 2.0") or 440 × 393 × 75 mm (17.3" × 15.5" × 3.0") | ≤ 1 kg (2.2 lb) or ≤ 5 kg (11 lb) |
