| Facial Detection and Analytics |
Face picture comparison, human face capture, face picture search<br/>4-ch human face capture (HD network camera, up to 4 MP, H.264/H.265) |
| Face Picture Library |
Up to 16 face picture libraries, with up to 100,000 face pictures in total (total capacity ≤ 4.7 GB) |
| Face Picture Comparison |
8-ch face picture comparison alarm |
| IP Video Input |
8-ch；Up to 12 MP resolution |
| HDMI Output |
1-ch, 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| VGA Output |
1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz, <br/>HDMI/VGA independent output<br/> |
| CVBS Output |
1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480 |
| Incoming Bandwidth |
80 Mbps/256 Mbps |
| Audio Output |
1-ch, RCA (Linear, 1 KΩ) |
| Two-Way Audio |
1-ch, RCA (2.0 Vp-p, 1 KΩ) |
| Decoding Format |
H.265+/H.265/H.264+/H.264/MPEG4 |
| Decoding Capability |
16-ch@1080p (30 fps), 4-ch@4K (30 fps), 3-ch@12 MP (30 fps) |
| Synchronous playback |
8-ch |
| Recording Resolution |
12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF/2CIF/CIF/QCIF |
| Stream Type |
Video, Video & Audio |
| Dual-stream |
Support |
| Audio Compression |
G.711ulaw/G.711alaw/G.722/G.726/MP2L2 |
| Network Protocol |
TCP/IP, DHCP, Safire Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS |
| Remote Connection |
128 |
| Network Interface |
1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
| SATA |
2 SATA interfaces |
| Capacity |
Up to 6 TB capacity for each disk |
| Serial Interface |
N/A |
| USB Interface |
Front panel: 1 × USB 2.0; Rear panel: 1 × USB 3.0 |
| Alarm In/Out |
4/1 |
| Power Supply |
12 VDC, 50 to 60 Hz |
| Consumption |
≤ 15 W |
| Working Temperature |
-10 °C to 55 °C (14 °F to 131 °F) |
| Working Humidity |
10% to 90% |
| Dimension (W × D × H) |
385 × 315 × 52 mm ( 15.2"× 12.4" × 2.0") | ≤ 1 kg (2.2 lb) |
| FCC |
Part 15 Subpart B, ANSI C63.4-2014 |
| CE |
EN50130-4, EN 61000-3-2,EN 61000-3-3, EN55032:2015 |
