| Face Picture Library |
Up to 16 face picture libraries, with up to 10,000 face pictures in total (each picture ≤ 512 KB, total capacity ≤ 150 MB) |
| Face Picture Comparison |
4-ch face picture comparison alarm |
| Facial Detection and Analytics |
Face picture comparison, human face capture, face picture search |
| Facial Detection and Analytics Performance |
1-ch human face capture (HD network camera, up to 8 MP , H.264/H.265) |
| Human/Vehicle Analysis |
Up to 4-ch 2 MP (H.264/H.265) video analysis for human and vehicle recognition to reduce false alarm |
| IP Video Input |
16 |
| Incoming Bandwidth |
160 Mbps |
| Outgoing Bandwidth |
256 Mbps |
| HDMI Output |
4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| VGA Output |
1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| Video Output Mode |
HDMI/VGA independent output |
| CVBS Output |
1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480 |
| Audio Output |
1-ch, RCA (Linear, 1 KΩ) |
| Two-Way Audio |
1-ch, RCA (2.0 Vp-p, 1 KΩ) |
| Decoding Format |
H.265,H.265+,H.264,H.264+,MPEG4 |
| Recording Resolution |
12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Playback Mode |
Normal/Smart, Event, Tag, Eternal File |
| Synchronous playback |
16-ch |
| Live View Window Division |
1/4/6/8/9/16 |
| Aux Port Window Division |
1/4/6/8/9/16 |
| Decoding Capability |
16-ch @ 1080p (30 fps) |
| Audio Compression |
G.711ulaw,G.711alaw,G.722,G.726,MP2L2 |
| Network Interface |
2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
| SATA |
2 SATA interfaces |
| Capacity |
Up to 8 TB capacity for each disk |
| Serial Interface |
RS-485 (half-duplex), RS-232, Keyboard |
| Alarm In/Out |
4/1 |
| USB Interface |
Front panel: 1 × USB 2.0; Rear panel: 1 × USB 3.0 |
| Power Supply |
≤ 40 W |
| Consumption |
≤ 15W |
| Working Temperature |
-10℃～＋55℃ |
| Working Humidity |
10％～90％ |
| Chassis |
1U |
| Dimension (W × D × H) |
385 × 315 ×52 mm ( 11.6"× 9.5" × 1.6") |
| |
≤ 1.6 kg (3.5 lb) |
