| IP Video Input |
128-ch |
| HDMI Output |
Two independent HDMI outputs of 4K resolution. Resolution: 4K (4096 × 2160), 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1080p (1920 × 1080)/60Hz, UXGA (1600 × 1200)/60Hz, SXGA (1280 × 1024)/60Hz, 720p (1280 × 720)/60Hz, XGA (1024 × 768)/60Hz |
| VGA Output |
1-ch. Resolution: 1080p (1920 × 1080)/60Hz, UXGA (1600 × 1200)/60Hz, SXGA (1280 × 1024)/60Hz, 720p (1280 × 720)/60Hz, XGA (1024 × 768)/60Hz |
| LCD Output |
Optional: One 7 inch LCD |
| Incoming Bandwidth |
576 Mbps/512 Mbps |
| TLS outgoing bandwidth |
128 Mbps, or 64 Mbps (when RAID is enabled) |
| Audio Output |
1-ch. RCA (2.0 Vp-p, 1 KΩ) |
| Two-Way Audio |
1-ch, RCA (2.0 Vp-p, 1 KΩ) |
| Decoding Format |
H.265, H.265+, H.264, H.264+,MPEG4, MJPEG (for Safire IP camera only) |
| Decoding Capability |
3-ch@12 MP (30fps), 5-ch@8 MP (30fps), 6-ch@6 MP (30fps), 10-ch@4 MP (30fps), 20-ch@1080p (30 fps) |
| Synchronous playback |
Up to 16 channels |
| Recording Resolution |
12 MP/8 MP/7 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Network Protocol |
IPv6, HTTPS, UPnP, SNMP, NTP, SADP, SMTP, NFS, iSCSI, PPPoE, DDNS |
| Camera Access Protocol |
Safire, ACTi, ARECONT, AXIS, BOSCH, BRICKCOM, CANON, HUNT, ONVIF (Version 2.5), PANASONIC, PELCO, RTSP, SAMSUNG, SONY, VIVOTEK, ZAVIO |
| Network Interface |
4, RJ45 10M/100M/1000M self-adaptive Ethernet interface |
| Interface |
N/A |
| RAID Type |
RAID0, RAID1, RAID5, RAID 6, and RAID10 |
| SATA |
16 SATA interfaces supporting hot-plug |
| eSATA |
1 × eSATA interface, 2 × mini SAS interface (optional) |
| Capacity |
Up to 10 TB for each HDD |
| Serial Interface |
RS-232; RS-485; Keyboard |
| USB Interface |
Front Panel: 2 × USB 2.0; Rear Panel: 2 × USB 3.0 |
| Alarm In/Out |
16/8 |
| Extension Board |
One extension board is supported with four 10M/100M/1000M optical interfaces (1.25 Gbps SFP module), eight RS-485 interfaces, and alarm interface of 32 alarm inputs and 16 alarm outputs. |
| Power Supply |
100 to 240 VAC, 50 to 60Hz, 5 A |
| Consumption |
≤ 140W |
| Working Temperature |
0 °C to + 50 °C (32 °F to 122 °F) |
| Working Humidity |
10% to 90% |
| Dimension (W × D × H) |
442 × 494 × 146 mm (17.4 × 19.4 × 5.7 inch) |
| |
≤ 16 kg (35.3 lb) |
