| Thermal sensor |
160x120 Vanadium Oxide |
| Optical sensor |
1/2.7” Progressive Scan CMOS 4 Megapixel |
| Main Stream rate |
1280x720, 704x576, 640x480, 352x288, 320x240 Term / 2688x1520, 1920x1080, 1280x720 (1~25FPS) Optics |
| Extra Stream rate |
704x576, 352x288, 320x240 Term / 704x576, 352x288, 176x144 (1~25FPS) Optics |
| Compression |
H.265 / H.264 / MJPEG |
| Lens |
1.8 mm (Therm) / 2.1 mm (Opt) |
| Range performance |
Human: 53 (Detection) / 13 (Recognition) / 7 (Identification) m
Vehicle: 162 (Detection) / 41 (Recognition) / 20 (Identification) m |
| VCA ranges |
Human: 14m
Vehicle: 42 m
Tº measurement (2x2m): 44 m
Tº measurement (1x1m): 22 m
Fire detection (2x2m): 108 m
Fire detection (1x1m): 54 m |
| Viewing angle |
90°×66.4° (Term) / 119.34° × 93.3° (Opt) |
| Thermal sensitivity |
< 40mK (0.05 º C) |
| Thermal measurement range |
-20 ~150 º C / ± 8 º C |
| Spectral range |
8~14μm |
| Pitch detector |
17μm |
| VCA |
Up to 8 VCA rules (linecrossing, intrusion, entry and exit of area) |
| Temperature rules |
Up to 21 rules (10 points, 10 areas y 1 line) |
| Intelligent functions |
Fire detection and alarm, line crossing, intrusion, abandoned/lost object |
| Audio In/Out |
1/ 1 line level 600 ohm |
| Alarm In/Out |
1/1 Relay |
| Internal memory |
Micro SD card up to 256GB |
| Network interface |
Ethernet 10/100 BaseT |
| Remote access |
WEB, CMS (DSS/PSS), Smartphone and NVR interface |
| Interoperability |
ONVIF |
| Power |
12VDC, 0.5A, max.6W; PoE IEEE802.3af, 0.14~0.22A, max.6.5W |
| Temp. operation |
-40º C ~ +65º C |
| Degree of protection |
Weatherproof IP66 |
| Dimensions |
138.3 mm (Fo) x 138.3 (An) x 123.1 (Al) mm |
| Weight |
940 g |
