| Image sensor |
Vanadium Oxide Uncooled Focal Plane Arrays |
| Pixel Interval |
17 μm |
| Response Waveband |
8 μm to 14 μm |
| NETD |
less than 40mk (@25°C,F#=1.0) |
| MRAD |
0.68 mrad |
| Field of View |
14.88° × 11.19° (H × V) |
| Min. Focusing Distance |
13 m |
| Aperture |
F 1.0 |
| VCA(Video Content Analysis) |
4 VCA rule types (Line Crossing, Intrusion, Region Entrance, and Region Exiting), up to 8 VCA rules. |
| Temperature Measurement |
3 temperature measurement rule types, 21 rules (10 points, 10 regions, and 1 line). |
| Temperature Range |
-20 °C to 150 °C (-4 °F to 302 °F) |
| Temperature Accuracy |
±8 °C (14.4 °F) |
| Fire Detection |
Dynamic fire point detection, up to 10 fire points detectable. |
| Main Stream |
50fps (384×288) |
| Sub stream |
50fps (384×288) |
| Third stream |
50fps (384×288) |
| Video compression |
H.265/H.264/MJPEG, H.265+/H.264+ encoding with Baseline/Main/High Profile |
| Audio compression |
G.711u/G.711a/G.722.1/MP2L2/G.726/PCM |
| Protocols |
IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS,NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE |
| Simultaneous live view |
Up to 20 |
| User/Host level |
Up to 32 users, 3 levels: Administrator, Operator, User |
| Security measures |
User authentication (ID and PW), MAC address binding, HTTPS encryption, IEEE 802.1x access control, IP address filtering |
| Alarm Input |
2-ch inputs (0-5V DC) |
| Alarm Output |
2-ch relay outputs, alarm response actions configurable |
| Alarm Action |
Preset/Patrol Scan/ Pattern Scan/SD Card Record/Relay Output/Smart capture/FTP upload/Email linkage |
| Audio Input |
1 3.5mm Mic in/Line in interface. Line input: 2-2.4V[p-p], output impedance:1KΩ±10% |
| Audio Output |
Linear Level; Impedance: 600Ω |
| Ethernet |
1 RJ45 10M/100M Self-adaptive Ethernet interface |
| SD Memory Card |
Built-in Micro SD card slot, support Micro SD/SDHC/SDXC card (up to 128G), support manual/alarm recording |
| Analog Video Output |
1.0V [p-p]/75Ω, PAL/NTSC/BNC |
| Application Programming |
Open-ended API, support ISAPI, Safire SDK and third-party management platform |
| Client |
Safire Control Center |
| Web Browser |
IE9+, chrome31-chrome44, Firefox 30-Firefox51, Safari 5.02+(mac) |
| Menu Language |
English |
| Power |
24 VAC± 25%, 12 VDC± 20%, two-core terminal block PoE (802.3at, class 4) |
| Power Consumption |
24 VAC± 25%: 0.84 A, 12 VDC ± 20%: 1.7 A, max. 8W (20W with De-icing Heater On), PoE (802.3at, class 4): 42.5 V to 57 V, 0.4 A to 0.5 A |
| Work Temperature/Humidity |
-40 °C to 65 °C (-40 °F to 149 °F), 90% or less |
| Protection Level |
IP66 Standard,TVS 6000V Lightning protection, surge protection, voltage transient protection |
| Dimensions / Weight |
352.4mm × 113.5mm × 113mm (13.9" × 4.45" × 4.45")<br/>Approx. 2kg (4.41lb) |
