| Brand |
SAFIRE |
| Image sensor |
1/1.8" Progressive Scan CMOS |
| Resolution |
4 Megapixel (2560x1440) |
| Minimum illumination |
0.002 Lux (color) / 0.0002 Lux (B/W) / 0 Lux (Laser up to 500m) |
| Compression |
H.265+/ H.265 / H.264+/ H.264 |
| Lens |
Varifocal 5.7~205.2 mm (Optical Zoom 36X) |
| Digital zoom |
16X |
| Electronic shutter |
1/1s~1/30,000s |
| Day / Night |
Removable mechanical ICR filter |
| Image improvements |
BLC, HLC, WDR, 3D-NR, AGC, AWB, MD, Privacy Masking, ROI |
| Video analysis |
Intelligent Autotracking (People and Vehicles), VCA: Tripwire | Area intrusion | Audio exception |
| Pan/Tilt Range |
Horizontal: 0°~360°, Vertical: -20°~90° auto flip |
| Manual speed |
Horizontal: 0.1° ~ 350°/sec, Vertical: 0.1° ~150°/s |
| Speed between Presets |
Horizontal: 280° /s, Vertical: 250° /s |
| Preset positions |
300 preset, 4 auto pattern, 8 auto tour, auto pan, auto scan |
| Internal memory |
MicroSD card, Max 256 GB |
| Audio |
1 input (Line In) / 1 output (Line Out) |
| Alarms |
7 in / 2 out |
| PTZ Control |
RS-485 and through network access |
| Network interface |
Ethernet 10 / 100M BaseT |
| Remote access |
Web browser, Safire Control Center Smartphone App and PC Software |
| Interoperability |
ONVIF (Profile S, G, T), PSIA, CGI |
| Power |
AC 24 V / 60W, Hi-PoE |
| Temp. operation |
-40º C ~ +70º C |
| Degree of protection |
IP67 / Surges 6000V |
| Material |
Aluminium alloy |
| Dimensions (without bracket) |
410 mm (H) x 266 (Ø) mm |
| Weight (without bracket) |
8000 g |
