| Brand |
SAFIRE |
| Image sensor |
1/2.8“ Progressive Scan CMOS Ultra Low Light |
| Resolution |
4Mpx (2560x1440) at 30 FPS |
| Minimum illumination |
0.005 Lux (color) / 0.001 Lux (B/N) @ F1.6 |
| Infrared lighting |
IR LEDs (100 m) |
| Compression |
H.265+/ H.265 / H.264+/ H.264 |
| Lens |
Varifocal 5~75 mm (Optical Zoom 15X) |
| Digital zoom |
16X |
| Electronic shutter |
1/1s~1/30,000s |
| Day / Night |
Removable mechanical ICR filter |
| Image improvements |
BLC, HLC, WDR, 3D-NR, AGC, AWB, MD, Privacy Masking, ROI, ANR |
| Video analysis |
VCA: Line crossing | Intrusion in area | Audio exception | Abandoned object |
| Pan/Tilt Range |
Horizontal: 0°~360°, Vertical: -15°~90° auto flip |
| Manual speed |
Horizontal: 0.1° ~ 80°/sec, Vertical: 0.1° ~80°/s |
| Speed between Presets |
Horizontal: 80° /s, Vertical: 80° /s |
| Preset positions |
300 preset, 8 patrol, 4 pattern scan, Auto Scan |
| Internal memory |
MicroSD card, Max 256 GB |
| Audio |
No |
| Alarms |
No |
| PTZ Control |
Through network access |
| Network interface |
Ethernet 10 / 100 BaseT |
| Remote access |
Web browser, Safire Control Center Smartphone App and PC Software |
| Interoperability |
ONVIF, PSIA, CGI |
| Power |
12 VDC, 2.0 A | PoE (802.3 at), 42.5 to 57 VDC, 0.6 A
Max.: 18 W, including max. 7W for IR |
| Temp. operation |
-30º C ~ +65º C |
| Degree of protection |
Waterproof IP66 / Overvoltages 4000V |
| Dimensions (without bracket) |
290 mm (H) x 164.5 (Ø) mm |
| Weight (without bracket) |
2000 g |
