FOV |
Horizontal field of view: 96.7° to 31.6° (wide-tele) ,Vertical field of view: 51.1° to 17.7° (wide-tele) ,Diagonal field of view: 115.1° to 36.3° (wide-tele) |
Zoom Speed |
Approx. 2 s (optical lens, wide-tele) |
Working Distance |
10 mm to 1500 mm (wide-tele) |
Aperture Range |
F1.5 to F2.7 |
Focal Length |
2.8 to 12 mm, 4 × optical zoom |
Image Enhancement |
BLC, HLC, defog, 3D DNR, regional exposure, regional focus |
Sub-Stream |
50Hz: 25fps (704 × 576, 640 × 480, 352 × 288),60Hz: 30fps (704 × 480, 640 × 480, 352 × 240) |
Max. Resolution |
2560 × 1440 |
Main Stream |
50Hz: 25fps (2560 × 1440, 2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720) 60Hz: 30fps (2560 × 1440, 2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720) |
Third Stream |
50Hz: 25fps (1280 × 720, 704 × 576, 640 × 480, 352 × 288) ,60Hz: 30fps (1280 × 720, 704 × 480, 640 × 480, 352 × 240) |
Protocol |
DSSS/OFDM |
Channel Bandwidth |
20/40MHz |
Security |
64/128-bit WEP,WPA/WPA2,WPS |
Wireless Range |
50 m |
Wireless Standards |
IEEE 802.11 b/g/n |
Frequency Range |
2.4 to 2.483GHz |
Transfer Rates |
11b:11Mbps; 11g:54Mbps; 11n:150Mbps |
Network Storage |
Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB; NAS (NPS, SMB/ CIPS), ANR |
Protocols |
IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour |
API |
Open-ended, support ONVIF, ISAPI, and CGI, support Safire SDK and Third-Party Management Platform |
Simultaneous Live View |
Up to 20 channels |
User/Host |
Up to 32 users. ,3 levels: Administrator, Operator and User |
Client |
Safire Control Center, Safire Connect |
Web Browser |
IE 8-11,Chrome 31+, Firefox 30+, Microsoft Edge 41.16299.726.0 |
Security Measures |
User authentication (ID and PW), Host authentication (MAC address); HTTPS encryption; IEEE 802.1x port-based network access control; IP address filtering |
Alarm Output |
1-ch alarm output |
Alarm Input |
1-ch alarm input |
Audio Input |
1-ch audio input |
Audio Output |
1-ch audio output |
Network Interface |
1 RJ45 10 M/100 M Ethernet Interface; PoE+ (802.3 at, class4) |
H.264+ |
Support |
H.265+ |
Support |
H.264 Type |
Baseline Profile/Main Profile/High Profile |
Video Compression |
Main Stream: H.265+/H.265/H.264+/H.264,Sub-Stream: H.265/H.264/MJPEG,Third Stream: H.265/H.264/MJPEG |
H.265 Type |
Main Profile |
Video Bitrate |
32 kbps to 16384 kbps |
Audio Compression |
G.711alaw/G.711ulaw/G.722/G.726/MP2L2/PCM |
Audio Bitrate |
64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 Kbps to 160 Kbps (MP2L2) |
SVC |
Support |
Image Sensor |
1/2.8" progressive scan CMOS |
Min. Illumination |
Color: 0.005 Lux @(F1.6, AGC ON),B/W: 0.001 Lux @(F1.6, AGC ON),0 Lux with IR |
White Balance |
Auto/Manual/ATW (Auto-tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp |
Shutter Time |
1/1 s to 1/30,000 s |
Day & Night |
IR Cut Filter |
Digital Zoom |
16× |
Privacy Mask |
24 programmable privacy masks, mask color configurable |
Focus Mode |
Auto/Semi-automatic/Manual |
WDR |
120 dB WDR |
IR Distance |
Up to 50 m |
Movement Range (Pan) |
0° to 350° |
Pan Speed |
Configurable, from 0.1°/s to 60°/s. Preset speed: 65°/s |
Movement Range (Tilt) |
0° to 90° |
Tilt Speed |
Configurable, from 0.1°/s to 50°/s. Preset speed: 60°/s |
Proportional Zoom |
Support |
Presets |
300 |
Patrol Scan |
No |
Pattern Scan |
No |
Power-off Memory |
Support |
Park Action |
Preset |
PTZ Status Display |
ON/OFF |
Preset Freezing |
Support |
Scheduled Task |
Preset/Dome Reboot/Dome Adjust/Aux output |
Basic Event Detection |
Motion detection, video tampering detection, alarm input, alarm output, exception (HDD full, HDD error, illegal login, network disconnected, IP address conflict) |
Smart Detection |
Face detection, intrusion detection, line crossing detection, region entrance detection, region exiting detection, object removal detection, unattended baggage detection, audio exception detection |
Smart Tracking |
ANR (Automatic Network Replenishment), dual-VCA |
ROI |
Main stream, sub-stream, and third stream respectively support 4 fixed areas, and dynamic face tracking. |
Material |
ADC12 + PC |
Dimensions / Weight |
179.3 mm × 120.5 mm × 182 mm (7.06" × 4.74" × 7.16")<br/>Approx. 1.125 kg (2.48 lb.) |
Protection Level |
IP66 standard, 6000V lightning protection, surge protection and voltage transient protection |
Power |
12 VDC, PoE 802.3at, max. 15 W (including max. 2.4 W for IR, 1.2 W for white light flashing) |
Working Temperature |
-30°C to 60°C (-22°F to 140°F) |
Working Humidity |
≤ 90% |
