Image Sensor |
1/2.5" Progressive Scan CMOS |
Min. Illumination |
Color: 0.028 Lux @(F2.0, AGC ON), 0 Lux with IR |
Shutter Speed |
1/3 s to 1/100,000 s |
Slow Shutter |
Yes |
Wide Dynamic Range |
120dB |
Day & Night |
IR Cut Filter |
Angle Adjustment |
Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355° |
Lens Type |
2.8 mm |
FOV |
2.8 mm, horizontal FOV: 102°, vertical FOV: 53°, diagonal FOV: 124° |
Aperture |
F2.0 |
Lens Mount |
Φ12 |
IR Range |
Up to 30 m |
Wavelength |
850nm |
Max. Resolution |
3840 × 2160 |
Main Stream |
50Hz: 20fps (3840 × 2160), 25fps (3072 × 1728, 1920 × 1080, 1280 × 720) ;60Hz: 20fps (3840 × 2160, 3072 × 1728, 1920 × 1080, 1280 × 720) |
Sub Stream |
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) ;60Hz: 20fps (640 × 480, 640 × 360, 320 × 240) |
Video Compression |
Main stream: H.265/H.264 ;Sub-stream: H.265/H.264/MJPEG |
Video Bit Rate |
32 Kbps to 16 Mbps |
H.264 Type |
Main Profile/High Profile |
H.265 Type |
Main Profile |
H.264+ |
No |
H.265+ |
No |
Region of Interest (ROI) |
Support 1 fixed region for main stream and sub-stream |
Environment Noise Filtering |
Yes |
Audio Sampling Rate |
8kHz/16kHz/32kHz/44.1kHZ/48kHz |
Audio Compression |
G722.1/G.711/G726/MP2L2/PCM/MP3 |
Audio Bit Rate |
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/8Kbps-320Kbps(MP3) |
Simultaneous Live View |
Up to 6 channels |
API |
ONVIF (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, Ehome |
Protocols |
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS |
User/Host |
Up to 32 users ,3 levels: Administrator, Operator and User |
Security |
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS 1.2, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, TLS1.2 |
Network Storage |
microSD/SDHC/SDXC card (128 GB), local storage and NAS (NFS,SMB/CIFS), ANR; Together with high-end Safire memory card, memory card encryption and health detection are supported. |
Client |
Safire Control Center, Safire Connect, Safire Central |
Web Browser |
Plug-in required live view: IE8+ Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+ Local Service: Chrome 41.0+, Firefox 30.0+ |
Alarm Trigger |
Motion detection, video tampering, network disconnected, IP address conflict, illegal login, HDD full, HDD error |
Day/Night Switch |
Day/Night/Auto/Schedule/Triggered by Alarm In |
DNR |
3D DNR |
Image Enhancement |
BLC/3D DNR/HLC |
Image Settings |
Saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser |
Audio |
1 input (line in/mic in, terminal block), 1 output ( two-core terminal block), mono sound |
Alarm |
1 input, 1 output (max. 12 VDC, 30 mA), terminal block |
Video Output |
1 HDMI™, type D, female plug (-M) |
On-board Storage |
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
Hardware Reset |
Yes |
Communication Interface |
1 RJ45 10M/100M self-adaptive Ethernet port |
Smart Event |
Line crossing detection, intrusion detection |
Face Detection |
Yes |
General Function |
Anti-flicke, heartbeat, mirror, privacy masks, password reset via e-mail, pixel counter, HTTP listening |
Startup and Operating Conditions |
IR on: -10 °C to 40 °C (14 °F to 104 °F), humidity 95% or less (non-condensing) ; IR off: -10 °C to 50 °C (14 °F to 122 °F), humidity 95% or less (non-condensing) |
Power Supply |
12 VDC ± 25%, Φ 5.5 mm coaxial power plug,PoE (802.3af, class 3) |
Power Consumption and Current |
12 VDC, 0.6 A, max. 7 W; PoE (802.3af, 36 V to 57 V), 0.3 A to 0.2 A, max. 8. 5W |
Camera Dimension |
Camera: Φ 119 × 90 mm (Φ 4.7" × 3.5")<br/>Camera: Approx. 520 g (1.1 lb.) <br/>With package: Approx. 750 g (1.7 lb.) |
Protection |
IK10 |
