| Image Sensor |
1/2.5" Progressive Scan CMOS |
| Min. Illumination |
Color: 0.028 Lux @ (F2.0, AGC ON), 0 Lux with IR |
| Shutter Speed |
1/3 s to 1/100,000 s |
| Slow Shutter |
Yes |
| Wide Dynamic Range |
120dB |
| Day & Night |
IR Cut Filter |
| Angle Adjustment |
Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355° |
| Focus |
Fixed |
| Lens Type |
Fixed lens, 2.8mm |
| FOV |
2.8 mm, horizontal FOV: 102°, vertical FOV: 53°, diagonal FOV: 124° |
| Aperture |
F2.0 |
| Lens Mount |
M12 |
| Aperture Type |
Fixed |
| IR Range |
Up to 30 m |
| Wavelength |
850nm |
| Max. Resolution |
3840 × 2160 |
| Main Stream |
50Hz: 12.5 fps (3840 × 2160), 20fps (3072 × 1728), 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720),60Hz: 15 fps (3840 × 2160), 20fps (3072 × 1728), 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720) |
| Sub Stream |
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240),60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
| Third Stream |
50Hz: 25fps (1280 × 720, 640 × 360, 352 × 288),60Hz: 30fps (1280 × 720, 640 × 360, 352 × 240) |
| Video Compression |
Main stream: H.265/H.264,Sub-stream: H.265/H.264/MJPEG,Third stream: H.265/H.264 |
| Video Bit Rate |
32 Kbps to 16 Mbps |
| H.264 Type |
Main Profile/High Profile |
| H.265 Type |
Main Profile |
| H.264+ |
Main stream supports |
| H.265+ |
Main stream supports |
| Scalable Video Coding (SVC) |
H.264 and H.265 encoding support |
| Environment Noise Filtering |
Yes |
| Audio Sampling Rate |
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Audio Compression |
G722.1/G.711/G726/MP2L2/PCM/MP3 |
| Audio Bit Rate |
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/8Kbps-320Kbps(MP3) |
| Simultaneous Live View |
Up to 6 channels |
| API |
ONVIF (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, Ehome |
| Protocols |
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS |
| User/Host |
Up to 32 users,3 levels: Administrator, Operator and User |
| Security |
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS 1.2, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, TLS1.2 |
| Network Storage |
Support Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR |
| Client |
Safire Control Center, Safire Connect, Safire Central |
| Web Browser |
Plug-in required live view: IE8+ Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+ Local Service: Chrome 41.0+, Firefox 30.0+ |
| Alarm Trigger |
Motion detection, video tampering, network disconnected, IP address conflict, illegal login, HDD full, HDD error |
| Day/Night Switch |
Day/Night/Auto/Schedule |
| Target Cropping |
No |
| DNR |
3D DNR |
| Image Enhancement |
BLC/3D DNR/HLC |
| Image Settings |
Saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser |
| Audio |
1 audio input (built-in microphone), mono sound |
| Video Output |
No |
| On-board Storage |
Built-in microSD/SDHC/SDXC slot, up to 128 GB |
| Hardware Reset |
Yes |
| Communication Interface |
1 RJ45 10M/100M self-adaptive Ethernet port |
| Basic Event |
Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error) |
| Smart Event |
Line crossing detection, intrusion detection, face detection |
| Face Detection |
Yes |
| Linkage Method |
Trigger recording: memory card, network storage, pre-record and post-record Trigger captured pictures uploading: FTP, HTTP, NAS, Email Trigger notification: HTTP, ISAPI, Email |
| Firmware Version |
5.6.3 |
| Web Client Language |
32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil) |
| General Function |
Anti-flicker, three streams, heartbeat, mirror, privacy masks, password reset via e-mail, pixel counter, HTTP listening |
| Startup and Operating Conditions |
-30 °C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing) |
| Power Supply |
12 VDC ± 25%, Φ 5.5mm ,PoE(802.3af, class 3) |
| Power Consumption and Current |
12 VDC, 0.6 A, max. 7 W; PoE: (802.3af, 36 V to 57 V), 0.3 A to 0.2 A, max. 8.5 W |
| Camera Dimension |
Camera: Φ 127.3 × 95.9 mm (5″ × 3. 8″)<br/>Package: 150 × 150 × 141 mm (5.9″ × 5.9″ × 5.6″)<br/>Camera: Approx. 560 g (1.2 lb.)<br/>With package: Approx. 800 g (1.8 lb.) |
| Protection |
IP66 |
