| Image Sensor |
1/2.7ʺ Progressive Scan CMOS |
| Min. Illumination |
Color: 0.005 Lux @ (F1.2, AGC ON), 0.0176 Lux @ (F2.25, AGC ON) <br/>B/W: 0.001 Lux @ (F1.2, AGC ON), 0.0035 Lux @ (F2.2.5, AGC ON) |
| Shutter Speed |
1/25 s – 1/100,000 s |
| DNR |
Digital WDR |
| Day & Night |
IR Cut Filter |
| Aperture |
F2.25 |
| FOV |
Horizontal FOV 104.5°, vertical FOV 70.5°, diagonal FOV 112° |
| Lens Mount |
M12 |
| Focal length |
2 mm fixed lens |
| Audio Compression |
G.711/G.722.1/G.726/MP2L2/PCM |
| Environment Noise Filtering |
Yes |
| Audio Sampling Rate |
8kHz/16kHz/32kHz/44.1kHz/48kHz |
| Audio I/O |
1 built-in mic<br/>1 input (line in, two-core terminal block), 1 output (two-core terminal block), mono sound<br/> |
| Basic Event |
Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error) |
| People Counting |
Counts people entering and exiting separately <br/>Supports real-time uploading and uploading by statistic cycle <br/>Sends email reports on daily, weekly, monthly or annually basis <br/>Supports target filtering by height |
| Region of Interest |
4 fixed regions for main stream and sub-stream |
| Linkage Method |
Upload to FTP/NAS, notify surveillance center, send email, trigger alarm output, trigger recording, trigger capture |
| Image Enhancement |
HLC, BLC, 3D DNR, defog |
| Day/Night Switch |
Day/Night/Auto/Schedule/Triggered by alarm input (-S) |
| Picture Overlay |
LOGO picture can be overlaid on video with 128 × 128 24bit bmp format |
| Image Settings |
Saturation, brightness, contrast, sharpness are adjustable by client software or web browser |
| Sub-Stream |
50Hz: 25fps (704 × 576, 640 × 480) <br/>60Hz: 30fps (704 × 480, 640 × 480)<br/> |
| Max. Resolution |
1920 × 1080 |
| Main Stream |
50Hz: 25fps (1920 × 1080, 1280 × 720); 60Hz: 30fps (1920 × 1080, 1280 × 720) |
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS |
| API |
ONVIF (PROFILE S, PROFILE G), ISAPI, SDK, Ehome (5.0) |
| Security |
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, RTP/RTSP over HTTPS, control timeout settings, security audit log |
| Simultaneous Live View |
Up to 20 channels |
| User/Host |
Up to 32 users<br/>3 levels: Administrator, Operator and User |
| Client |
Safire Control Center, Safire Connect |
| Web Browser |
IE8+, Chrome 41.0-44, Mozilla Firefox30.0-51, Safari8.0-11 |
| Communication Interface |
1 RJ45 10M/100M Ethernet port<br/>1 RS-485 interface (half duplex, Safire, Pelco-P, Pelco-D, self-adaptive) |
| Alarm (-S model) |
1 input, 1 output (max. 24 VDC,1A) |
| EMC |
47 CFR Part 15, Subpart B; EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014; AS/NZS CISPR 32: 2015; ICES-003: Issue 6, 2016; KN 32: 2015, KN 35: 2015 |
| Safety |
UL 60950-1, IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IS 13252(Part 1):2010+A1:2013+A2:2015 |
| Protection |
IP67 (IEC 60529-2013) |
| H.264+ |
Main stream supports |
| H.265+ |
Main stream supports |
| H.264 Type |
Baseline Profile/Main Profile/High Profile |
| Video Compression |
Main stream: H.265+/H.265/H.264+/H.264 <br/>Sub stream: H.265/H.264/MJPEG |
| H.265 Type |
Main Profile |
| Video Bitrate |
32 Kbps to 16 Mbps |
| Audio Bitrate |
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-160Kbps(MP2L2) |
| SVC |
H.265 and H.264 support |
| IR Range |
Up to 6 m IR range |
| Wavelength |
850 nm |
| Firmware Version |
5.5.90 |
| Web Client Language |
32 languages. English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil) |
| General Function |
Anti-flicker, heartbeat, mirror, password protection, watermark, IP address filter |
| Storage Conditions |
-30 °C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing) |
| Power Supply |
12 VDC±20%, reverse polarity protection, Φ5.5mm coaxial power plug <br/>12 VDC, PoE (36 to 57 VDC, 802.3af), Calss3 |
| Material |
Front cover: plastic, camera body: metal |
| Dimensions / Weight |
Camera: 168 mm × 61 mm × 41 mm (6.6" × 2.4" × 1.6" ) <br/>With Package: 235 mm × 120 mm × 125 mm (9.2" × 4.7" × 4.9")<br/>Camera: Approx. 435 g (1 lb.) <br/>With package: 725 g (1.6 lb)<br/> |
| Operating Conditions |
-30 °C to +45 °C (-22 °F to +113 °F), Humidity 95% or less (non-condensing) |
| Power Consumption |
12 VDC, 0.66 A, max. 8 W, PoE (802.3 af, 36 to 57 VDC), 0.23 A to 0.14 A, max. 8.3 W |
