| Image Sensor |
1/1.8" Progressive Scan CMOS |
| Min. Illumination |
Color: 0.003 Lux @ (F1.6, AGC ON), 0 Lux with IR |
| Shutter Speed |
1/3 s to 1/100,000 s |
| Slow Shutter |
Yes |
| Wide Dynamic Range |
120 dB |
| Day & Night |
IR Cut Filter |
| Angle Adjustment |
Pan: 0° to 355°, tilt: 0° to 90°, rotate: 0° to 360° |
| Lens Type |
2.8 to 12 mm |
| FOV |
Horizontal FOV: 108.1° to 45.5° , vertical FOV: 58.4° to 25.7° , diagonal FOV: 127.3° to 52.1° |
| Aperture |
F1.4 |
| Lens Mount |
Φ14 |
| IR Range |
Up to 60 m |
| Wavelength |
850 nm |
| Max. Resolution |
3840 × 2160 |
| Main Stream |
50Hz: 20fps (3840 × 2160, 3072 × 1728), 25fps (2688 × 1520,1920 × 1080, 1280 × 720) <br/>60Hz: 20fps (3840 × 2160, 3072 × 1728), 30fps (2688 × 1520,1920 × 1080, 1280 × 720)<br/> |
| Sub Stream |
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) <br/>60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)<br/> |
| Third Stream |
50Hz: 25fps (1280 × 720, 640 × 480, 640 × 360, 320 × 240) <br/>60Hz: 30fps (1280 × 720, 640 × 480, 640 × 360, 320 × 240)<br/> |
| Video Compression |
Main stream: H.265+/H.264+/H.265/H.264 <br/>Sub-stream: H.265/H.264/MJPEG <br/>Third stream: H.265/H.264<br/> |
| Video Bit Rate |
32 Kbps to 16 Mbps |
| H.264 Type |
Baseline Profile/Main Profile/High Profile |
| H.265 Type |
Main Profile |
| Scalable Video Coding (SVC) |
H.264 and H.265 encoding support |
| Region of Interest (ROI) |
1 fixed region for main stream, sub-stream and third stream |
| Environment Noise Filtering |
Yes |
| Audio Sampling Rate |
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Audio Compression |
G.711/G.722.1/G.726/MP2L2/PCM/MP3 |
| Audio Bit Rate |
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/8Kbps-320Kbps(MP3) |
| Simultaneous Live View |
Up to 6 channels |
| API |
ONVIF (PROFILE S, PROFILE G), ISAPI, SDK |
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS |
| User/Host |
Up to 32 users, 3 levels: administrator, operator and user |
| Security |
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, TLS1.2 |
| Network Storage |
microSD/SDHC/SDXC card (256 GB), local storage and NAS (NFS,SMB/CIFS), ANR |
| Client |
Safire Control Center, Safire Connect, Safire Central |
| Web Browser |
Plug-in required live view: IE8+, Chrome 41.0-44, Firefox30.0-51, Safari8.0-11 <br/>Plug-in free live view: Chrome 57.0+, Firefox 52.0+<br/> |
| Day/Night Switch |
Day/Night/Auto/Schedule/Triggered by Alarm In |
| Image Enhancement |
BLC, HLC, 3D DNR |
| Image Settings |
Saturation, brightness, contrast, sharpness, AGC and white balance adjustable by client software or web browser |
| Audio |
1 audio input (line in), two-core terminal block; 1 audio output(line out), two-core terminal block |
| Alarm |
1 alarm input, 1 alarm output (max. 24 VAC/24 VDC@500 mA) |
| On-board Storage |
Built-in micro SD slot, up to 256 GB |
| Hardware Reset |
Reset via reset button on camera body, web browser and client software |
| Communication Interface |
1 RJ45 10M/100M self-adaptive Ethernet port |
| Basic Event |
Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error), scene change detection |
| Perimeter Protection |
Line crossing detection, intrusion detection, region entrance detection, region exiting detection (Human & Vehicle classification) |
| Linkage Method |
Upload to FTP/NAS/memory card, notify surveillance center, send email, alarm output, audible warning, trigger capture |
| Web Client Language |
32 languages <br/>English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)<br/> |
| General Function |
Anti-flicker, three streams, heartbeat, mirror, privacy masks, pixel counter |
| Storage Conditions |
-30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing) |
| Startup and Operating Conditions |
-30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing) |
| Power Supply |
12 VDC ± 25%, two-core terminal block; reverse polarity protection; PoE (802.3at, class 4) |
| Power Consumption and Current |
12 VDC, 1.12 A, max. 13.5 W; PoE (802.3at, 42.5 V to 57 V), 0.5 A to 0.3 A, max. 15 W |
| Dimension / Weight |
Camera: Φ 144 × 333 mm (Φ 5.7" × 13.1") <br/>With package: 385 × 190 × 180 mm (15.2" × 7.5" × 7.1")<br/>Camera: approx. 1430 g (3.2 lb.) <br/>With package: approx. 2490 g (5.5 lb.) |
| EMC |
FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015) |
| Safety |
UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015); LOA (IEC/EN 60950-1) |
| Environment |
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
| Protection |
Ingress protection: IP66 (IEC 60529-2013), IK10(IEC 62262:2002) |
