| Image Sensor |
1/1.8" Progressive Scan CMOS |
| Max. Resolution |
2688 × 1520 |
| Min. Illumination |
Color: 0.0005 Lux @ (F1.2, AGC ON);<br/>B/W: 0.0001 Lux @ (F1.2, AGC ON)，0 Lux with IR |
| Shutter Time |
1 s to 1/100,000 s |
| Day & Night |
IR cut filter<br/>Blue glass module to reduce ghost phenomenon |
| Focal Length & FOV |
2.8 to 12 mm, horizontal FOV: 42.5° to 15.1°, vertical FOV: 23.3° to 8.64°, diagonal FOV: 49.6° to 17.3° |
| Focus |
Auto, semi-auto, manual |
| Iris Type |
P-iris |
| Aperture |
2.8 to 12 mm: F1.2 to F2.5 |
| DORI |
Wide:<br/>2.8 to 12 mm: D: 60 m, O: 23.8 m, R: 12 m, I: 6 m<br/>Tele:<br/>2.8 to 12 mm: D: 149 m, O: 59.1 m, R: 29.8 m, I: 14.9 mm |
| Supplement Light Type |
IR |
| Supplement Light Range |
100 m |
| Smart Supplement Light |
Yes |
| IR Wavelength |
850 nm |
| Main Stream |
50 Hz: 25 fps (1920 × 1080, 1280 × 720)<br/>60 Hz: 30 fps (1920 × 1080, 1280 × 720) |
| Sub-Stream |
50 Hz: 25 fps (704 × 576, 640 × 480)<br/>60 Hz: 30 fps (704 × 480, 640 × 480) |
| Third Stream |
50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)<br/>60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) |
| Fourth Stream |
50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)<br/>60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) |
| Fifth Stream |
50 Hz: 25 fps (704 × 576, 640 × 480)<br/>60 Hz: 30 fps (704 × 480, 640 × 480) |
| Video Compression |
Main stream: H.265+/H.265/H.264+/H.264<br/>Sub-stream/Third stream/Fourth stream/Fifth stream: H.265/H.264/MJPEG |
| Video Bit Rate |
32 Kbps to 8 Mbps |
| H.264 Type |
Baseline Profile/Main Profile/High Profile |
| H.265 Type |
Main Profile |
| Bit Rate Control |
CBR/VBR |
| Scalable Video Coding (SVC) |
H.265 and H.264 encoding |
| Region of Interest (ROI) |
4 fixed regions for each stream |
| Target Cropping |
Yes |
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, SRTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP,UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS |
| Simultaneous Live View |
Up to 20 channels |
| API |
Open Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, ISUP |
| User/Host |
Up to 32 users. 3 user levels: administrator, operator and user |
| Security |
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2 |
| Network Storage |
NAS (NFS, SMB/CIFS), auto network replenishment (ANR) <br/>Together with high-end Safire memory card, memory card encryption and health detection are supported |
| Client |
Safire Control Center, Safire Connect, Safire Central |
| Web Browser |
Plug-in required live view: IE8+ <br/>Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+ <br/>Local service: Chrome 41.0+, Firefox 30.0+ |
| Image Parameters Switch |
Yes |
| Image Settings |
Saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser |
| Day/Night Switch |
Day, Night, Auto, Schedule, Alarm Trigger, Video Trigger |
| Wide Dynamic Range (WDR) |
140 dB |
| SNR |
≥ 52 dB |
| Image Enhancement |
BLC, HLC, Defog, 3D DNR |
| Picture Overlay |
LOGO picture can be overlaid on video with 128 × 128 24bit bmp format |
| Image Stabilization |
EIS |
| Video Output |
1 Vp-p Composite Output (75 Ω/CVBS) (Only for debugging) |
| Ethernet Interface |
1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port |
| On-Board Storage |
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB |
| Alarm |
2 input, 2 outputs (max. 24 VDC, 1 A) |
| Reset Key |
Yes |
| Basic Event |
Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, abnormal reboot, HDD full, HDD error), video quality diagnosis, vibration detection |
| Smart Event |
Intrusion detection, scene change detection, audio exception detection, defocus detection<br/>Line crossing detection, up to 4 lines configurable Intrusion detection, up to 4 regions configurable <br/>Region entrance detection, up to 4 regions configurable <br/>Region exiting detection, up to 4 regions configurable |
| Linkage |
Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, trigger capture |
| Perimeter Protection |
Line crossing, intrusion, region entrance, region exiting <br/>Support alarm triggering by specified target types |
| Road Traffic and Vehicle Detection |
Blocklist and allowlist: up to 10,000 records <br/>Captures vehicle that has no license plate <br/>Support license plate recognition of motorcycles (only in checkpoint scenario) <br/>Support vehicle attribute detection, including vehicle type, color, brand, etc. (City Street mode is recommended.) |
| Metadata |
Metadata of road traffic is supported. |
| Power |
12 VDC ± 20%, 1.19 A, max. 14.28 W, three-core terminal block<br/>PoE: 802.3at, Type 2, Class 4, 42.5 V to 57 V), 0.396 A to 0. 295 A, max. 16.8 W |
| Dimension |
Ø144 × 347 mm (Ø5.7" × 13.7") |
| Package Dimension |
405 × 190 × 180 mm (15.9" × 7.5" × 7.1") |
| |
Approx. 1950 g (4.2 lb.) |
| With Package Weight |
Approx. 3070 g (6.7 lb.) |
| Storage Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Startup and Operating Conditions |
-40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Language |
33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil),Ukrainian |
| General Function |
Anti-flicker, 5 streams, EPTZ, heartbeat, mirror, privacy mask, flash log, password reset via email, pixel counter |
| Heater |
Yes |
| EMC |
FCC (47 CFR Part 15, Subpart B); <br/>CE-EMC (EN 55032: 2015, EN 61000-3-2:2019, EEN 61000-3-3:2013+A1:2019, EN 50130-4: 2011 +A1: 2014);<br/>RCM (AS/NZS CISPR 32: 2015); <br/>IC (ICES-003: Issue 7); <br/>KC (KN 32: 2015, KN 35: 2015) |
| Safety |
UL (UL 62368-1); <br/>CB (IEC 62368-1:2014+A11); <br/>CE-LVD (EN 62368-1:2014/A11:2017); <br/>BIS (IS 13252(Part 1):2010/ IEC 60950-1 : 2005); <br/>LOA (IEC/EN 60950-1) |
| Environment |
CE-RoHS (2011/65/EU); <br/>WEEE (2012/19/EU); <br/>Reach (Regulation (EC) No 1907/2006) |
| Protection |
IK10 (IEC 62262:2002), IP67 (IEC 60529-2013) |
| Automotive and Railway |
EN50121-4 |
| Other |
PVC FREE |
