| Image Sensor |
1/1.8″ Progressive Scan CMOS |
| Min. Illumination |
Color: 0.001 Lux @ (F1.2, AGC ON); B/W: 0.0003 Lux @ (F1.2, AGC ON) |
| Shutter Speed |
1 s to 1/100,000 s |
| Slow Shutter |
Yes |
| P/N |
P/N |
| Wide Dynamic Range |
140 dB |
| Day & Night |
IR cut filter |
| Power-off Memory |
Yes |
| Focus |
Auto, semi-auto, manual. |
| Focal Length & FOV |
2.8 to 12 mm, horizontal FOV: 107.3° to 39.8°, vertical FOV: 55.9° to 22.3°, diagonal FOV: 130.1° to 45.7° |
| Aperture |
2.8 to 12 mm: F1.2 to 2.5 |
| Lens Mount |
Integrated |
| Blue Glass Module |
Blue glass module to reduce ghost phenomenon. |
| P-Iris |
Yes |
| IR Range |
2.8 to 12 mm: 50 m |
| IR Wavelength |
850 nm |
| Smart Supplement Light |
Yes |
| Max. Resolution |
1920 × 1080 |
| Main Stream |
50Hz: 50fps (1920 × 1080, 1280 × 720)<br/>60Hz: 60fps (1920 × 1080, 1280 × 720) |
| Sub-Stream |
50Hz: 25fps (704 × 576, 640 × 480)<br/>60Hz: 30fps (704 × 480, 640 × 480) |
| Third Stream |
50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)<br/>60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) |
| Fourth Stream |
50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)<br/>60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) |
| Fifth Stream |
50Hz: 25fps (704 × 576, 640 × 480)<br/>60Hz: 30fps (704 × 480, 640 × 480) |
| Custom Stream |
50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)<br/>60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) |
| Video Compression |
Main stream: H.265+/H.265/H.264+/ H.264<br/>Sub-stream/Third stream/Fourth stream/Fifth stream/custom stream: H.265/H.264/MJPEG |
| Video Bit Rate |
32 Kbps to 16 Mbps |
| H.264 Type |
Baseline Profile/Main Profile/High Profile |
| H.265 Type |
Main Profile |
| H.264+ |
Main Stream supports |
| H.265+ |
Main Stream supports |
| Bit Rate Control |
CBR/VBR |
| Stream Type |
Main stream/sub-stream/third stream/fourth stream/fifth stream/custom stream |
| Scalable Video Coding (SVC) |
H.265 and H.264 support |
| Region of Interest (ROI) |
4 fixed regions for each stream |
| Environment Noise Filtering |
Yes |
| Audio Sampling Rate |
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Audio Compression |
G.711/G.722.1/G.726/MP2L2/PCM/MP3 |
| Audio Bit Rate |
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/32Kbps(PCM)/8-320Kbps(MP3) |
| Audio Type |
Mono sound |
| Simultaneous Live View |
Up to 20 channels |
| API |
Open Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, ISUP |
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, SRTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP,UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS |
| Smooth Streaming |
Yes |
| User/Host |
Up to 32 users. 3 user levels: administrator, operator and user |
| Security |
Password protection, complicated password, HTTPS encryption,802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2 |
| Network Storage |
microSD/SDHC/SDXC card (256 GB) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR)<br/>Together with high-end Safire memory card, memory card encryption and health detection are supported. |
| Client |
Safire Control Center, Safire Connect, Safire Central |
| Web Browser |
Plug-in required live view: IE8+<br/>Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+<br/>Local service: Chrome 41.0+, Firefox 30.0+ |
| Smart IR |
The IR LEDs on camera should support Smart IR function to automatically adjust power to avoid image overexposure. |
| Day/Night Switch |
Day, Night, Auto, Schedule, Triggered by Alarm In, Triggered by Video |
| Target Cropping |
Yes |
| Distortion Correction |
Yes |
| Picture Overlay |
LOGO picture can be overlaid on video with 128 × 128 24bit bmp format |
| Image Enhancement |
BLC, HLC, 3D DNR, Defog, EIS, Distortion Correction |
| Image Parameters Switch |
Yes |
| Image Settings |
Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser |
| SNR |
≥52 dB |
| Alarm |
2 input, 2 outputs (max. 24 VDC, 1 A) |
| Audio |
No |
| RS-485 |
No |
| Video Output |
1 Vp-p Composite Output(75Ω/CVBS)(For debugging only) |
| On-Board Storage |
Built-in micro SD/SDHC/SDXC slot, up to 256 GB |
| Hardware Reset |
Yes |
| Ethernet Interface |
1 RJ45 10M/100M/1000M self-adaptive Ethernet port |
| Heater |
Yes |
| Wiegand |
No |
| Basic Event |
Motion detection, video tampering alarm, vibration detection, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error) |
| Smart Event |
Line crossing detection, up to 4 lines configurable<br/>Intrusion detection, up to 4 regions configurable<br/>Region entrance detection, up to 4 regions configurable<br/>Region exiting detection, up to 4 regions configurable<br/>Unattended baggage detection, up to 4 regions configurable<br/>Object removal detection, up to 4 regions configurable<br/>Scene change detection, audio exception detection, defocus detection |
| Counting |
Yes |
| Perimeter Protection |
Line crossing, intrusion, region entrance, region exiting<br/>Support alarm triggering by specified target types (human and vehicle)<br/>Filtering out mistaken alarm caused by target types such as leaf, light, animal, and flag, etc. |
| Road Traffic and Vehicle Detection |
Blocklist and allowlist: up to 10000 records<br/>Captures vehicle that has no license plate<br/>Support license plate recognition of motorcycles (only in checkpoint scenario)<br/>Support vehicle attribute detection, including vehicle type, color, brand, etc. (City Street mode is recommended.) |
| Linkage Method |
Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, trigger capture<br/>Trigger recording: memory card, network storage, pre-record and post-record<br/>Trigger captured pictures uploading: FTP, SFTP, HTTP, NAS, Email<br/>Trigger notification: HTTP, ISAPI, alarm output, Email<br/> |
| Online Upgrade |
Yes |
| Dual Backup |
Yes |
| Firmware Version |
V5.5.130 |
| Web Client Language |
33 languages<br/>English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
| General Function |
Anti- flicker, 5 streams and up to 5 custom streams, EPTZ, heartbeat, mirror, privacy masks, flash log, password reset via e-mail, pixel counter |
| Software Reset |
Yes |
| Storage Conditions |
-40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Startup and Operating Conditions |
-40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Power Supply |
12 VDC ± 20%, three-core terminal block, reverse polarity protection; PoE: 802.3at, Type 2 Class 4 |
| Power Consumption and Current |
12 VDC, 1.33 A, max. 16.0 W<br/>PoE: (802.3at, 42.5V-57V), 0.43 A to 0.31 A, max. 18.0 W |
| Power Interface |
Three-core terminal block |
| Dimensions / Weight |
Camera: Ø144 × 347 mm (Ø5.7″ × 13.7″)<br/>Package: 405 × 190 × 180 mm (15.9″ × 7.5″ × 7.1″)<br/>Camera: 1920 g (4.2 lb.)<br/>Package: 3060 g (6.7 lb.) |
| Metadata |
Metadata of intrusion detection, line crossing detection, region entrance detection, region exiting detection, unattended baggage detection, object removal are supported. |
| Class |
Class B |
| EMC |
FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015) |
| Safety |
UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015); LOA (IEC/EN 60950-1) |
| Environment |
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
| Protection |
IK10 (IEC 62262:2002), IP67 (IEC 60529-2013) |
