| Image Sensor |
1/3\" progressive scan CMOS |
| Min. Illumination |
Color: 0.01 Lux @ (F2.0 AGC ON) B/W: 0 Lux with IR |
| Shutter Speed |
1/3 s to 1/100000 s |
| Slow Shutter |
Yes |
| Wide Dynamic Range |
120 dB |
| Day & Night |
IR cut filter |
| Angle Adjustment |
Pan: 0 to 360 tilt: 0 to 180 rotate: 0 to 360 |
| Focal Length & FOV |
horizontal FOV 98.0 vertical FOV 53.1 diagonal FOV 114.7 |
| Lens Mount |
M12 |
| Focus |
Fixed |
| Aperture |
F2.0 |
| IR Wavelength |
850 nm |
| IR Range |
Up to 30 m |
| Max. Resolution |
2560 x 1440 |
| Main Stream |
50 Hz: 20 fps (2560 1440)
25 fps (2304 1296 1920 1080 1280 720)
60 Hz: 20 fps (2560 1440)
30 fps (2304 1296 1920 1080 1280 720) |
| SubStream |
50 Hz: 25 fps (640 480 640 360)
60 Hz: 30 fps (640 480 640 360) |
| Video Compression |
Main stream: H.265/H.264
Substream: H.265/H.264/MJPEG |
| Video Bit Rate |
32 Kbps to 8 Mbps |
| H.264 Type |
Baseline Profile/Main Profile/High Profile |
| H.265 Type |
Main Profile |
| H.264+ |
Main stream supports |
| H.265+ |
Main stream supports |
| Region of Interest (ROI) |
1 fixed region for main stream |
| Audio Compression |
G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC |
| Audio Bit Rate |
64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC) |
| Audio Sampling Rate |
8 kHz/16 kHz |
| Environment Noise Filtering |
Yes |
| Protocols |
TCP/IP ICMP HTTP HTTPS FTP DHCP DNS DDNS RTP RTSP RTCP PPPoE NTP UPnP SMTP SNMP IGMP 802.1X QoS IPv6 Bonjour IPv4 UDP SSL/TLS |
| Simultaneous Live View |
Up to 6 channels |
| API |
Open Network Video Interface ISAPI |
| User/Host |
Up to 32 users. 3 levels: administrator operator and user |
| Client |
Safire Control Center Safire Connect |
| Web Browser |
Plugin required live view: IE 10+
Plugin free live view: Chrome 57.0+ Firefox 52.0+
Local service: Chrome 57.0+ Firefox 52.0+ |
| Image Settings |
Saturation brightness contrast sharpness AGC white balance adjustable by client software or web browser |
| Day/Night Switch |
Auto Schedule Day Night |
| Image Enhancement |
BLC 3D DNR |
| Ethernet Interface |
1 RJ45 10 M/100 M selfadaptive Ethernet port |
| Builtin Microphone |
No |
| Hardware Reset |
No |
| Basic Event |
Motion detection video tampering exception |
| Linkage Method |
Upload to FTP notify surveillance center send email |
| Camera Material |
Metal & Plastic |
| Camera Dimension |
177.6 mm 66.2 mm 67.8 mm (7.0\" 2.6\" 2.7\") |
| Package Dimension |
216 mm 121 mm 118 mm (8.5\" 4.8\" 4.6\") |
| Camera Weight |
Approx. 270 g (0.6 lb.) |
| With Package Weight |
Approx. 490 g (1.1 lb.) |
| Storage Conditions |
30 C to 60 C (22 F to 140 F). Humidity 95% or less (noncondensing) |
| Startup and Operating Conditions |
30 C to 60 C (22 F to 140 F). Humidity 95% or less (noncondensing) |
| Web Client Language |
English Ukrainian |
| General Function |
Antiflicker heartbeat mirror password protection privacy mask watermark IP address filter |
| Firmware Version |
V5.5.120 |
| Power Consumption and Current |
12 VDC 0.4 A max. 5 W
PoE: (802.3af 36 V to 57 V) 0.2 A to 0.15 A max. 6.5 W |
| Power Supply |
12 VDC 25%
PoE: 802.3af Class 3 |
| Power Interface |
5.5 mm coaxial power plug |
| EMC |
FCC SDoC (47 CFR Part 15 Subpart B); CEEMC (EN 55032: 2015 EN 6100032: 2014 EN 6100033: 2013 EN 501304: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC VoC (ICES003: Issue 6 2016); KC (KN 32: 2015 KN 35: 2015) |
| Safety |
UL (UL 609501); CB (IEC 609501:2005 + Am 1:2009 + Am 2:2013 IEC 623681:2014); CELVD (EN 609501:2005 + Am 1:2009 + Am 2:2013 IEC 623681:2014); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015) |
| Environment |
CERoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
| Protection |
IP67 (IEC 605292013) |
