| Video/Audio input |
| Video compression |
H.264+/H.264 |
| Analog video input |
8-ch |
| HDTVI input |
1080p25, 1080p30, 720p25, 720p30 |
| AHD input |
1080p25, 1080p30, 720p25, 720p30 |
| HDCVI input |
1080p25, 1080p30, 720p25, 720p30 |
| CVBS input |
Support |
| IP video input |
Up to 8-ch |
| Audio compression |
G.711u |
| Audio input |
1-ch, RCA (2.0 Vp-p, 1 KΩ)
4-ch via coaxial cable |
| Video/Audio output |
| HDMI/VGA output |
1-ch, 1920 × 1080/60Hz,1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| Encoding resolution |
When 1080p lite mode not enabled: 720p/WD1/4CIF/VGA/CIF
When 1080p lite mode enabled: 1080p lite/HD 720p lite/WD1/4CIF/VGA/CIF |
| Main stream Frame rate |
When 1080p lite mode enabled: 1080p lite/HD 720p lite/WD1/4CIF/VGA@12fps; CIF@25fps (P)/30fps (N)
When 1080p lite mode not enabled: For 720p stream access: 720p/WD1/4CIF/VGA@12fps; CIF@25fps (P)/30fps (N) For SD stream access: WD1/4CIF/VGA/CIF@25fps (P)/30fps (N) |
| Sub-stream Frame Rate |
CIF/QVGA/QCIF@12fps |
| Video bit rate |
32 Kbps to 4 Mbps |
| Audio output |
1-ch, RCA (Linear, 1 KΩ) |
| Audio bit rate |
64 Kbps |
| Dual stream |
Support |
| Stream type |
Video, Video & Audio |
| Synchronous playback |
8-ch |
| Network management |
| Remote connections |
128 |
| Network protocols |
TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS, ONVIF |
| Hard disk |
| SATA Interface |
1 SATA interface |
| Hard Disk Capacity |
Up to 6 TB capacity for each disk |
| External interface |
| Two-way audio input |
1-ch, RCA (2.0 Vp-p, 1 KΩ) |
| Network interface |
1, RJ45 10M/100M self-adaptive Ethernet interface |
| USB interface |
Rear panel: 2 × USB 2.0 |
| General |
| Power supply |
12 VDC |
| Consumption (without HDD) |
≤ 12 W |
| Working temperature |
-10 ºC to +55 ºC (14 ºF to 131 ºF) |
| Working humidity |
10% to 90% |
| Dimensions (W × D × H) |
200 × 200 × 45 mm (7.9 × 7.9 × 1.8 inch) |
| Weight (without HDD) |
≤ 0.8 kg (1.8 lb) |
