| Brand |
SAFIRE |
| Image sensor fixed lenses |
4 x 1/2“ Progressive Scan CMOS |
| Sensor resolution |
16 Megapixel |
| Max. Resolution |
Panorama + ePTZ: Panorama CH: 1920x1080; ePTZ CH: 1920 × 1080
Panorama mode: 4800x2688
Original mode: 2688x1520
Split Panorama: 2400x1344 |
| Main Stream |
Panorama + ePTZ: Panorama CH: 1920x1080, 960x540 (1~25 FPS); ePTZ CH: 1920x1080, 1280x720 (1~25 FPS)
Panorama mode: 4800x2688, 3840x2160, 2688x1520 (1~25 FPS)
Original mode: 2688x1520 (1~25 FPS) |
| Sub Stream |
Panorama mode: 1920x1080, 960x540 (1~25 FPS) |
| Fixed lenses |
2.8 mm (H: 180º, V: 90º) |
| Minimal lens illumination |
0.009 Lux (color) / 0.0009 Lux (B/W) @ F1.6 / 0 Lux with IR |
| Infrared lighting lenses |
IR LEDs (20 m) |
| Compression |
H.265+ / H.264+ / H.265 / H.264 |
| Electronic shutter |
1/25s ~ 1/100,000s |
| Day / Night |
Removable mechanical ICR filter |
| Image improvements |
BLC, HLC, DWDR, 3D-DNR, AGC, AWB, MD, Privacy Masking, ROI, ANR |
| Display Modes |
Panorama / Original / Panorama + ePTZ / Split Panorama |
| Basic Functions |
Motion detection, Sabotage alarm, Network loss exception, Memory full |
| People Density |
YES (Only Panorama mode supports this function) |
| Audio |
1 input (Line In) / 1 output (Line Out) |
| Alarms |
2 input / 2 relay |
| Network interface |
RJ 45: Ethernet 10/100/1000M BaseT, SFP: FC Interface (Single mode, Single fiber) |
| Internal memory |
Slot for MicroSD card up to 256 GB |
| Remote access |
Web browser, Safire Control Center Smartphone App and PC Software |
| Interoperability |
ONVIF, PSIA, CGI |
| Power |
DC 12 V / 1.6 A, Max. 24W, PoE IEEE802.3at |
| Temp. operation |
-40º C ~ +60º C |
| Degree of protection |
Waterproof IP67 / Anti-vandal IK10 |
| Dimensions (without bracket) |
190 (h) x x 207 (Ø) mm |
| Base dimensions |
3 screws (Ø150 ) mm |
| Weight (without bracket) |
3000 g |
