| Brand |
Safire Smart |
| Range |
I1 |
| Image sensor |
1/2.9" Progressive Scan CMOS |
| Maximum resolution |
6 Megapixel (2160x2160) |
| Minimum illumination |
Colour: 0.068 Lux @(F2.0, AGC ON), 0 Lux with IR |
| IR range |
30 m |
| Day/Night |
Removable mechanical ICR filter |
| Electronic Shutter |
1/2~1/100.000 s |
| Resolution |
- Fisheye + panorama + 3 PTZ
25fps@(2160×2160 / 1920×1920 / 1440×1440 / 960×960 / 480×480)
3x 15fps@(1920×1080 / 704×576), 15fps@(960×540 / 480×240)
- Fisheye + 4 PTZ
50Hz: 25fps@(2160×2160 / 1920×1920 / 1440×1440 / 960×960 / 480×480)
4x 15fps@(960× 540 / 480×240) |
| Compression |
H.265 / H.264 / MJPEG |
| Bitrate |
64 Kbps ~ 8 Mbps |
| Lens |
1.1 mm (360º) |
| Installation |
Ceiling or Wall |
| Image improvements |
WDR, BLC, HLC, 3D-DNR, AWB, ROI, Mirror Function, Privacy Mask, ROI |
| Motion Detection |
Yes |
| Audio |
Integrated microphone, 1 input and 1 output |
| Audio Compression |
G711A / U |
| Alarms |
1 Input / 1 Relay |
| Video output |
1 BNC CVBS output |
| Network interface |
Ethernet 10 / 100M BaseT |
| Internal memory |
MicroSD card up to 256GB |
| Remote access |
Web Browser, Smartphone App Safire Smart, PC Software Safire Smart VMS |
| Interoperability |
ONVIF |
| Power |
DC 12 V / 950 mA / 10.5 W max. / IEEE802.3af PoE |
| Degree of protection |
Weatherproof IP67 |
| Material |
Metallic |
| Temp. operation |
-30º C ~ +60º C |
| Dimensions |
130 (Φ) x 41 (Fo) mm |
| Weight |
650 g |
