Varijante |
COSEC DOOR FOP |
COSEC DOOR FOPQ |
Različiti načini pristupa |
Finger, Card and PIN |
Finger, Card and PIN |
Displej |
128 x 64 Dot Matrix Display |
128 x 64 Dot Matrix Display |
Tastatura |
16 Touch Sense Keys |
16 Touch Sense Keys |
Broj korisnika |
50,000 (Max. 9600 in 1:N Mode) |
50,000 (Max. 9600 in 1:N Mode) |
Broj uzoraka po korisniku |
do 10 |
Up to Ten (Single Template per Finger Mode) or Up to Five (Dual Template per Finger Mode) |
Kapacitet za uzorke |
9600 in 1:N Mode and 1 lac in 1:1 Mode |
9600 in 1:N Mode and 1 lac in 1:1 Mode |
Broj kartica po korisniku |
do 2 |
Up to Two |
Memorija za događaje |
500,000 |
500,000 |
Tipovi kartica |
Proximity Card (EM Prox and HID Prox) and Smart Card (Mifare and HID iCLASS) (Card Module Required) |
Proximity Card (EM Prox and HID Prox) and Smart Card (Mifare and HID iCLASS) (Card Module Required) |
Mobilna mreža |
Yes (2G/3G Support) |
Yes (2G/3G Support) |
RS-485 |
Yes (115.2 Kbps) |
Yes (115.2 Kbps) |
Eternet |
Yes (10/100 Mbps on Ethernet) |
Yes (10/100 Mbps on Ethernet) |
Izlazni prekidač |
Yes |
Yes |
Senzor za vrata |
Programmable NO, NC and Supervised |
Programmable NO, NC and Supervised |
Door Lock Relay |
Form C, SPDT Relay (Max [email protected] VDC) |
Form C, SPDT Relay (Max [email protected] VDC) |
Napajanje za bravu |
Internal 12VDC @ 0.5A or External |
Internal 12VDC @ 0.5A or External |
Aux-IN |
Programmable NO, NC and Supervised |
Programmable NO, NC and Supervised |
Aux-OUT |
Form C, SPDT Relay (Max 2A @ 30VDC) |
Form C, SPDT Relay (Max 2A @ 30VDC) |
Reader Interface types |
RS-232, and Wiegand IN only |
RS-232, and Wiegand IN only |
Tipovi čitača |
1 Port for Card Reader/Finger Reader/Card Finger Combo Reader/Third Party Wiegand reader |
1 Port for Card Reader/Finger Reader/Card Finger Combo Reader/Third Party Wiegand reader |
USB |
2 USB Ports (1 for Data Transfer and 1 for 2G-3G Dongle) |
2 USB Ports (1 for Data Transfer and 1 for 2G-3G Dongle) |
Buzzer |
Yes |
Yes |
LED |
4 LEDs (Status, Alarm, Allowed, Denied) |
4 LEDs (Status, Alarm, Allowed, Denied) |
CPU |
400 MHz ARM 9 based Processor |
400 MHz ARM 9 based Processor |
Flash Memorija |
256MB Flash |
256MB Flash |
RAM Memorija |
128MB DDR2 |
128MB DDR2 |
Input Power |
12VDC @ 2A |
12VDC @ 2A |
Reader Power Output |
Internal 12 VDC @ 0.5 A or External |
External Internal 12 VDC @ 0.5 A or External |
Rezervna baterija |
No |
No |
Vlažnost |
5% to 85% RH Non-condensing |
5% to 85% RH Noncondensing |
Operativna temperatura |
0°C to + 50°C (32°F to 122°F) |
0°C to + 50°C (32°F to 122°F) |
Tamper Detection |
Yes |
Yes |
Sertifikat |
CE and RoHS |
CE and RoHS |
STQC |
No |
Verified |
Dimenzije (mm) |
100X220X56 |
100X220X56 |
Težina (kgs) |
0.65 |
0.65 |
