Range |
Uniview |
Image sensor |
1/3.2” Progressive Scan CMOS |
Maximum resolution |
2 Megapixel (1920x1080) |
Lens |
2.8 mm (H: 99.7° V: 55.1° D: 117.1°) |
Viewing Angle (FOV) |
99.7° (H), 55.1° (V), 117.1° (D) |
Video output |
BNC, supports TVI, AHD, CVI and CVBS |
Main Stream rate |
TVI/AHD/CVI: 1080P@25fps (default), 1080P@30fps; 720P@25fps, 720P@30fps CVB: PAL, NTSC |
Minimum illumination |
0,02 lux (F2.0, AGC ON)0 lux (IR ON) |
Infrared range |
20 m |
Image improvements |
Global (default), BLC, HLC, DWDR |
Day / Night |
Auto (default), Day, Night |
Invert image (Flip) |
Supports horizontal rotation of 180º and vertical rotation of 180º |
Power |
DC 12V / 1.99W |
Surge protection |
4kV |
Temp. operation |
-30º C ~ 60º C |
Dimensions |
85mm (Φ) * 72mm (H) |
Weight |
89.3 g |
