| Brand |
Uniarch |
| Video format |
HDTVI / HDCVI / AHD / CVBS / IP |
| Video inputs |
8CH BNC |
| Hybrid configuration |
Up to 8 IP Channels (4Mpx) replacing all the BNC channels |
| Video outputs |
1 HDMI Full HD, 1 VGA |
| Audio inputs |
1 Channel RCA |
| Audio outputs |
1 Channel RCA |
| Bidirectional audio |
Reusing the audio input/output |
| Display resolution |
1920x1080, 1600x1200, 1280x1024, 1280x720, 1024x768 |
| Maximum IP recording resolution |
4 Mpx |
| Analog cameras supported |
TVI / AHD: 5MP@12FPS; 4MP@15FPS; 1080P@30FPS; 720P@30FPS
CVI: 4MP@15FPS;1080P@30FPS; 720P@30FPS |
| Main Stream recording encoding |
TVI/CVI/AHD: 5MPLite@6fps; 4MPLite@8fps; 2MPLite@15FPS; 2MP@8FPS; 720P@15FPS |
| Extra Stream recording encoding |
D1@6FPS; D1@8FPS; D1@15FPS; |
| Recording method |
Manual, programmed, motion detection |
| Internal memory |
1 HDD SATA 3.5" of up to 6TB (not included) |
| External interface |
2 x USB (Mouse and backup) / RJ45 10M/100M/1000M (Ethernet) / RS485 |
| Remote access |
Web Browser, CMS Software (EZStation), Smartphone (EZView/EZLive) |
| Power |
DC 12V / 8W |
| Dimensions / Weight |
46 (H) x 260 (W) x 243 (D) mm / 1 kg |
