| Video |
1 CH: ADAS Camera (Embedded) |
| Video inputs |
2CH additional (1 AHD + 1 IP)
*A total of up to 3CH |
| Video output |
1 Video OUT |
| Sensor |
ADAS: 1/2.7" CMOS |
| Resolution |
ADAS: 5 Mpx |
| Audio |
Microphone and Speaker |
| Input Resolution |
ADAS: 5MP @ 20FPS |
| Recording resolution |
Main stream: 5MP@20 FPS(ADAS)+1080P@20 FPS(DSC)+1080P@20 FPS(AHD) + 1080P@20 FPS(IPC)
Sub-stream: 4 × CIF@30 FPS |
| Audio compression |
APCM/G.711/G.726 |
| Lens |
ADAS: 2.8 mm (H: 103º, V: 71º)
DSC: 2.1 mm (H: 148º, V: 82º) |
| S/N |
> 48dB |
| Camera type |
ADAS:
Lane departure
Crosswalk
Collision Risk
Front vehicle safety distance |
| Summary of Functions |
Live viewing, video recording, video playback, network streaming and GPS positioning |
| 4G Communication |
LTE FDD: B1/B3/B7/B8/B20/B28A
LTE TDD: B38/B40/B41
WCDMA: B1/B8
GSM: B3/B8 |
| Wi-Fi communication |
2.4 GHz |
| Bluetooth communication |
Supported |
| Image enhancement |
Brightness, Chroma, Contrast, Saturation, Sharpness, BLC and DWDR adjustment |
| Video compression |
H.265 / H.264 |
| Positioning |
GPS |
| Sensors |
Accelerometer: 6 axes (collision detection, hard cornering, hard braking)
SIM: SIM card slot
1x RS232
1x CAN |
| Alarms |
2 Inputs |
| CAN Bus |
Supported |
| Network Protocols |
HTTP, TCP, ARP, UDP, UDP, FTP, DHCP, DNS, IPV4, NTP |
| Storage |
2x microSD card slots up to 256GB per slot |
| Management Software |
CEIBA II Centralized Server |
| Temperature Range |
-40ºC to 70ºC |
| Power |
DC 9-36V, Max. 11.5W |
| Certificates |
Emark, CE-RED, FCC-ID, EN50155-EMC, UKCA, EN50155, ROHS, REACH, PTCRB, AT&T, Verizon |
| Installation |
On windshield |
