| Brand |
Safire Smart |
| Range |
B1 Night Colour Economic |
| Image sensor |
1/3" Progressive Scan CMOS |
| Maximum resolution |
2 Megapixel (1920x1080) |
| Minimum illumination |
Color: 0.003 Lux @(F1.0, AGC ON)
Night Color, color image 24/7h |
| Lighting Scope |
Dual lighting:
IR up to 40m
White LED up to 40m |
| Day/Night |
Removable mechanical ICR filter |
| Electronic Shutter |
1/2~1/100.000 s |
| Main Stream rate |
25 FPS (1080P, 720P) |
| Extra Stream rate |
25 FPS (720P, D1, CIF) |
| Third Stream Rate |
25 FPS (D1, 480x240, CIF) |
| Compression |
H.265 / H.264 |
| Bitrate |
64 Kbps ~ 8 Mbps |
| Lens |
2.8mm mm fixed |
| Field Of View (FOV) |
H: 97°, V: 52°, D: 115° |
| Range performance |
59 m (D), 24 m (O), 12 m (R), 6 m (I) |
| Image improvements |
WDR, BLC, HLC, 3D-DNR, AWB, ROI, Mirror Function, Privacy Mask, ROI |
| Motion Detection |
Yes |
| Smart Features |
Smart Events: dropped object, removed object, Video exceptions (change of scene, video loss, ...) |
| Audio |
Built-in microphone, 1 Input |
| Audio Compression |
G711A / U |
| Network interface |
Ethernet 10 / 100M BaseT |
| Internal memory |
MicroSD card up to 256GB |
| Remote access |
Web Browser, Smartphone App Safire Smart, PC Software Safire Smart VMS |
| Interoperability |
ONVIF |
| Power |
DC 12 V / 708 mA / 8.5 W max. / IEEE802.3af PoE |
| Degree of protection |
Weatherproof IP67 |
| Material |
Metallic |
| Temp. operation |
-30º C ~ +60º C |
| Dimensions |
80.3 (H) x 80.5 (W) x 217.8 (D) mm |
| Weight |
690 g |
