| Brand |
Safire Smart |
| Range |
B1 |
| Image sensor |
1/3" Progressive Scan CMOS |
| Maximum resolution |
2 Megapixel (1920x1080) |
| Minimum illumination |
Colour: 0.0462 Lux @(F1.6, AGC ON), 0 Lux with IR |
| IR range |
20 m |
| Day/Night |
Removable mechanical ICR filter |
| Electronic Shutter |
1/3~1/100.000 s |
| Main Stream rate |
25 FPS (1080P, 720P) |
| Extra Stream rate |
25 FPS (D1, VGA, CIF, 480x240) |
| Third Stream Rate |
25 FPS (D1, 480x240, CIF) |
| Compression |
H.265+, H.265, H.264+, H.264 |
| Bitrate |
64 Kbps ~ 8 Mbps |
| Lens |
2.8 mm |
| Viewing Angle (FOV) |
H: 87°, V: 48°, D: 103° |
| Range performance |
49 m (D), 19 m (O), 8 m (R), 5 m (I) |
| Image improvements |
DWDR, BLC, HLC, 3D-DNR, AWB, ROI, ROI, Mirror function, Privacy masking, ROI |
| Motion Detection |
Yes |
| Smart Features |
Area intrusion, Line crossing, abandoned object, removed object, Video exceptions (change of scene, video loss, ...) |
| Audio |
Integrated microphone |
| Audio Compression |
G711A / U |
| Network interface |
Ethernet 10 / 100M BaseT |
| Remote access |
Web Browser, Smartphone App Safire Smart, PC Software Safire Smart VMS |
| Interoperability |
ONVIF |
| Power |
DC 12 V / 300 mA / 4 W max. / IEEE802.3af PoE |
| Degree of protection |
Weatherproof IP67 |
| Material |
Plastic |
| Temp. operation |
-20º C ~ +55º C |
| Dimensions |
73.70 (H) x 74.70 (W) x 161.5 (D) mm |
| Weight |
240 g |
