| Image Sensor |
5 MP CMOS |
| Max. Resolution |
2560 (H) × 1944 (V) |
| Min. Illumination |
0.01 Lux@(F1.2, AGC ON), 0 Lux with IR |
| Shutter Time |
PAL: 1/25 s to 1/50, 000 s<br/>NTSC: 1/30 s to 1/50, 000 s |
| Day & Night |
ICR |
| Angle Adjustment |
Pan: 0 to 360°, Tilt: 0 to 75°,Rotation 0 to 360° |
| Signal System |
PAL/NTSC |
| Lens Type |
3.6 mm fixed lens |
| Focal Length & FOV |
3.6 mm, horizontal FOV: 80.1°, vertical FOV: 63.7°, diagonal FOV: 105.9° |
| Lens Mount |
M12 |
| Audio |
AOC (Audio over Coax cable) |
| Image Parameters Switch |
STD/HIGH-SAT |
| Image Settings |
Brightness, Sharpness, Mirror, Smart IR |
| Frame Rate |
TVI: 5MP@20fps, 4MP@30fps, 4MP@25fps, 1080P@30fps, 1080P@25fps<br/>CVI: 4MP@30fps, 4MP@25fps<br/>AHD: 5MP@20fps, 4MP@30fps, 4MP@25fps<br/>CVBS: PAL/NTSC<br/> |
| Day/Night Mode |
Auto/Color/BW (Black and White) |
| Wide Dynamic Range (WDR) |
Digital WDR |
| White Balance |
ATW/MANUAL |
| AGC |
Support |
| Video Output |
Switchable TVI/AHD/CVI/CVBS |
| Material |
Metal |
| Dimension |
82.6 mm × 90 mm × 79.37 mm (3.25" × 3.54" × 3.12") | Approx. 289.5 g (0.64 lb.) |
| Operating Condition |
-40° C to 60° C (-40° F to 140° F), Humidity 90% or less (no condensation) |
| Communication |
Safire-C |
| Language |
English |
| Power Supply |
12 VDC ± 25%<br/>*You are recommended to use one power adapter to supply the power for one camera. |
| Consumption |
Max. 3.7 W<br/> |
| IR Range |
Up to 30 m |
| Protection |
IP67 |
