| Brand |
Safire Smart |
| Range |
B1 economic |
| Image sensor |
1/3" Progressive Scan CMOS |
| Maximum resolution |
4 Megapixel (2560x1440) |
| Minimum illumination |
Colour: 0.03 Lux @(F1.6, AGC ON), 0 Lux with IR |
| IR range |
30 m |
| Day/Night |
Removable mechanical ICR filter |
| Electronic Shutter |
1/2~1/100.000 s |
| Main Stream rate |
25 FPS (4Mpx, 3Mpx, 1080P, 720P) |
| Extra Stream rate |
25 FPS (720P, D1, CIF) |
| Third Stream Rate |
25 FPS (D1, 480x240, CIF) |
| Compression |
H.265 / H.264 |
| Bitrate |
64 Kbps ~ 8 Mbps |
| Lens |
2.8 mm |
| Field Of View (FOV) |
H: 98°, V: 53°, D: 116° |
| Range performance |
61 m (D), 24 m (O), 12 m (R), 6 m (I) |
| Image improvements |
WDR, BLC, HLC, 3D-DNR, AWB, ROI, Mirror Function, Privacy Mask, ROI |
| Motion Detection |
Yes |
| Intelligent functions |
VCA Rules: Area intrusion, line crossing, abandoned object, removed object, video exception (change of scene) |
| Audio |
No |
| Audio Compression |
G711A / U |
| Network interface |
Ethernet 10 / 100M BaseT |
| Internal memory |
No |
| Remote access |
Web Browser, Smartphone App Safire Smart, PC Software Safire Smart VMS |
| Interoperability |
ONVIF |
| 3 Axis |
Yes |
| Power |
DC 12 V / 375 mA / < 4 W máx. / IEEE802.3af PoE |
| Degree of protection |
Waterproof IP67, Anti-vandal IK10 |
| Material |
Metal and plastic |
| Temp. operation |
-30º C ~ +60º C |
| Dimensions |
110 (Ø) × 83.3 (H) mm |
| Weight |
500 g |
