| Image Sensor |
1/3" Progressive Scan CMOS |
| Max. Resolution |
2560 × 1440 |
| Min. Illumination |
Color: 0.005 Lux @(F1.6, AGC ON), B/W: 0 Lux with IR |
| Shutter Speed |
1/3 s to 1/100,000 s |
| Wide Dynamic Range |
120 dB |
| Day & Night |
IR Cut Filter |
| Angle Adjustment |
Pan: 0° to 360°, tilt: 0° to 90°, rotation: 0° to 360° |
| Lens Type |
Varifocal lens, motor-driven lens, 2.8 to 12 mm |
| Focal Length & FOV |
2.8 to 12 mm: horizontal FOV 102° to 31°, vertical FOV 55° to 18°, diagonal FOV 122° to 36° |
| Lens Mount |
Ø14 |
| Iris Type |
Fixed |
| Aperture |
F1.6 |
| IR Wavelength |
850 nm |
| IR Range |
Up to 50 m |
| Main Stream |
50 Hz:25 fps (2304 × 1296, 1920 × 1080, 1280 × 720) |
| Sub-Stream |
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) |
| Video Compression |
Main stream: H.265+/H.265/H.264+/H.264<br/>Sub-stream: H.265/H.264/MJPEG |
| Video Bit Rate |
32 Kbps to 8 Mbps |
| H.264 Type |
Baseline Profile/Main Profile/High Profile |
| H.265 Type |
Main Profile |
| Region of Interest (ROI) |
1 fixed region for main stream |
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP™, SMTP, IGMP, 802.1X, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS |
| Simultaneous Live View |
Up to 6 channels |
| API |
Open Network Video Interface, ISAPI |
| User/Host |
Up to 32 users. 3 levels: administrator, operator and user |
| Client |
Safire Control Center, Safire Connect |
| Web Browser |
Plug-in required live view: IE 10+<br/>Plug-in free live view: Chrome 57.0+, Firefox 52.0+<br/>Local service: Chrome 57.0+, Firefox 52.0+ |
| Image Settings |
Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser |
| Day/Night Switch |
Auto, Schedule, Day, Night |
| Image Enhancement |
BLC, 3D DNR |
| Ethernet Interface |
1 RJ45 10 M/100 M self-adaptive Ethernet port |
| On-Board Storage |
Built-in memory card slot, support microSD card, up to 256 GB |
| Audio |
n/a |
| Alarm |
n/a |
| Reset Key |
Yes |
| Basic Event |
Motion detection, video tampering alarm, exception |
| Linkage |
Upload to FTP, notify surveillance center, send email, upload to memory card, trigger recording, trigger capture |
| Power |
12 VDC ± 25%, 0.9 A, max. 11 W, Ø5.5 mm coaxial power plug<br/>PoE: 802.3af, Class 3, 36 V to 57 V, 0.36 A to 0.23 A, max. 12.9 W |
| Camera Material |
Metal |
| Camera Dimension |
Ø105 mm × 244.4 mm (Ø4.1" × 9.6") |
| Package Dimension |
315 mm × 137 mm × 141 mm (12.4" × 5.4" × 5.6") |
| Camera Weight |
Approx. 1035 g (2.3 lb.) |
| With Package Weight |
Approx. 1550 g (3.4 lb.) |
| Storage Conditions |
-30 °C to 60 °C (22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Startup and Operating Conditions |
-30 °C to 60 °C (22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Language |
English, Ukrainian<br/> |
| General Function |
Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter |
| EMC |
FCC SDoC (47 CFR Part 15, Subpart B);<br/>CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014);<br/>RCM (AS/NZS CISPR 32: 2015); <br/>IC VoC (ICES-003: Issue 6, 2016);<br/>KC (KN 32: 2015, KN 35: 2015) |
| Safety |
UL (UL 60950-1);<br/>CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014);<br/>CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014);<br/>BIS (IS 13252(Part 1):2010+A1:2013+A2:2015) |
| Environment |
CE-RoHS (2011/65/EU);<br/>WEEE (2012/19/EU);<br/>Reach (Regulation (EC) No 1907/2006) |
| Electrical Safety Protection |
IP67 (IEC 60529-2013) |
