| Image Sensor |
1/3" Progressive Scan CMOS |
| Min. Illumination |
Color: 0.028 Lux @ (F2.0, AGC ON), 0 Lux with IR |
| Shutter Speed |
1/3 s to 1/100,000 s |
| Slow Shutter |
Yes |
| Wide Dynamic Range |
DWDR |
| Day & Night |
IR Cut Filter |
| Angle Adjustment |
Pan: 0° to 355°, tilt: 0° to 75° |
| Focus |
Fixed |
| Lens Type |
Fixed lens, 2.8 mm |
| FOV |
horizontal FOV: 100°, vertical FOV: 55°, diagonal FOV: 117° |
| Aperture |
F2.0 |
| Lens Mount |
M12 |
| Aperture Type |
Fixed |
| IR Range |
Up to 30 m |
| Wavelength |
850nm |
| Max. Resolution |
2560 × 1440 |
| Main Stream |
50Hz: 20fps (2560 × 1440, 2304 x 1296, 1920 x 1080, 1280 × 720)<br/>60Hz: 20 fps (2560 × 1440, 2304 x 1296, 1920 x 1080, 1280 × 720) |
| Sub Stream |
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)<br/>60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
| Video Compression |
Main stream: H.265/H.264<br/>Sub-stream: H.265/H.264/MJPEG |
| H.264 Type |
Baseline Profile/Main Profile |
| H.265 Type |
Main Profile |
| Video Bit Rate |
32 Kbps to 8 Mbps |
| Basic Event |
Motion detection, video tampering alarm, exception (illegal login) |
| Linkage Method |
Saturation, brightness, contrast, sharpness, AGC and white balance adjustable by client software or web browser |
| Day/Night Switch |
Day/Night/Auto/Schedule |
| S/N |
>50dB |
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour |
| API |
ONVIF (PROFILE S), ISAPI, SDK |
| Security |
Password protection, complicated password, IP address filter, Watermark, HTTPS encryption, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, 802.1X authentication (EAP-MD5) |
| Simultaneous Live View |
Up to 6 channels |
| User/Host |
Up to 32 users,3 levels: Administrator, Operator and User |
| Client |
Safire Control Center, Safire Connect, Safire Central |
| Web Browser |
IE8+, Chrome 31.0-44, Firefox30.0-51, Safari8.0+ |
| Communication Interface |
1 RJ45 10M/100M self-adaptive Ethernet port |
| General Function |
Anti-flicker, heartbeat, mirror, privacy mask |
| Reset |
Reset via web browser and client software |
| Startup and Operating Conditions |
-30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing) |
| Storage Conditions |
-30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing) |
| Power Supply |
12 VDC ± 25%, Φ 5.5mm ,PoE(802.3af, class 3) |
| Power Consumption and Current |
12 VDC, 0.30 A, max. 3.6 W; PoE (802.3af, 36 V to 57 V), 0.2 A to 0.1 A, max. 4.5 W |
| Material |
Front cover: plastic, bottom base: metal |
| Dimensions |
Camera: Φ114 mm × 82.4 mm (Φ4.5" × 3.2" )<br/>With package: 134 × 134 × 108 mm (5.3" × 5.3" × 4.3") |
| Weight |
Camera: approx. 400 g (0.9 lb.)<br/>With package: approx. 580 g (1.3 lb.) |
| EMC |
47 CFR Part 15, Subpart B; EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014; AS/NZS CISPR 32: 2015; ICES-003: Issue 6, 2016; KN 32: 2015, KN 35: 2015 |
| Safety |
UL 60950-1, IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IS 13252(Part 1):2010+A1:2013+A2:2015, IEC/EN 60950-1 |
| Chemistry |
2011/65/EU, 2012/19/EU, Regulation (EC) No 1907/2006 |
| Protection |
Ingress protection: IP67 (IEC 60529-2013), IK10(IEC 62262:2002) |
