| Brand |
Safire Smart |
| Range |
E1 High-quality, high-performance professional |
| Image sensor |
1/2.7" CMOS |
| Maximum resolution |
5 Mpx (2560x1936) |
| Resolution |
5Mpx@20FPS |
| Lens |
2.8 mm |
| Minimum illumination |
0.01 Lux @(F1.2, AGC ON) |
| Infrared lighting |
0 Lux / IR range up to 50 m (ICR) |
| Day / Night |
Auto / Colour / BW (Black and White) |
| Video output |
1 x BNC switchable between HDTVI / HDCVI / AHD / CVBS |
| Video output switching |
Via Switch |
| Basic functions |
OSD menu (remote) |
| Configurable OSD functions |
DWDR, DNR, AWB, ATW, BLC, AGC, Mirror, Smart IR |
| Lens Adjustment |
3 Axis |
| Power |
DC 12 V / 500 mA, 6W max |
| Degree of protection |
Weatherproof IP67 |
| Temp. operation |
-30º C ~ +50º C |
| Material |
Metal body and plastic bracket |
| Dimensions |
80.5 (H) x 80.5 (W) x 217.70 (D) mm |
| Weight |
570 g |
