| System |
| Main Processor |
Quad Cortex A53 |
| Operating System |
Embedded LINUX |
| Video |
| Input |
32CH(4000*3000,3840*2160,2592x1944, 2048x1536, 1920×1080, 1280×960, 1280×720, etc) |
| Output |
1*HD,1*VGA |
| Audio |
| Input |
1 Port RCA, support 32CH IPC audio input |
| Output |
1 Port RCA(Linear, 1kΩ), HD output |
| Audio Bit Rate |
64kbps |
| Audio Compression standard |
G711U, G711A, AAC |
| Intercom |
support (two-way) |
| Alarm |
| Sensor Input |
4CH |
| Output |
1CH |
| Motion Detection |
32Channel, MD Zones: 396 (22 × 18) |
| Trigger Events |
Recording, Email, FTP, Snapshot, Buzzer and Screen Tips, alarm output |
| Display |
| HD Output1 |
4K(3840*2160), 2560*1440,1920*1080, 1280*1024, 1280*720, 1024*768 |
| HD Output2 |
N/A |
| VGA |
Resolution:1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| Display Split |
36CH/25CH/17CH/16CH/13CH/10CH/9CH/8CH/6CH/4CH/1CH |
| Digital Zoom |
YES |
| OSD |
Camera Title, Time, Recording, Motion Detection, Event Alarm |
| Recording |
| Video Compression |
H265/H264/H265+/H264+ |
| Resolution |
12MP(4000*3000),8MP(3840×2160),5MP(2592×1944),4MP(2688×1520/2560×1440), 3MP(2048×1536), 1080P(1920×1080),960P(1280x960), 720P(1280×720),D1 (720×576/720×480) |
| Record Rate |
PAL :12MP@32CHx25fps,8MP@32CHx25fps,5MP@32CH×25fp,4MP@32CHx25fp,3MP@32CH×25fp, 1080P@32CH×25fp, 960P@32CH×25fp,720P@32CH×25fp, D1@32CH×25fp
NTSC: 12MP@32CHx30fps,8MP@32CHx30fps,5MP@32CH×30fp,4MP@32CH×30fp,3MP@32CH×30fp, 1080P@32CH×30fp, 960P@32CH×30fp, 720P@32CH×30fp, D1@32CH×30fp |
| Record Mode |
Manual\Timer\Motion Detection\ Alarm\Smart Event |
| Playback & Backup |
| Local Sync Playback |
3CH 12MP@30fps,4CH 8MP@30fps,6CH 5MP@30fps,8CH 4MP@30fps, 16CH 1080P@30fps, 16CH 960P@30fps, 16CH 720P@30fps,16CH D1@30fps |
| Decode Capability |
1080P(1920x1080)@480fps |
| Remote Sync Playback |
YES |
| Search Mode |
ALL, Timing Video, Motion Detection, Alarm,Tag search,Smart Event,Pictrue,Log |
| Playback Functions |
Play, pause, fast forward, rewind, previous frame, next frame, electronic zoom, clip, audio |
| Backup Mode |
USB Device/Network |
| Network |
| Interface |
1xRJ45 10M/100/1000MAdaptive Ethernet Interface |
| Incoming Bandwidth |
320Mb |
| Network Functions |
IPv6,TCP/IP, HTTP,HTTPS, UPnP, DNS, NTP, SMTP, DHCP, FTP, DDNS, RTSP, RTCP, p2p,PPPOE |
| Onvif |
onvif S,onvif T |
| Web Browser |
Edge,IE8-11, Google Chrome , Firefox ,Safari |
| CMS Software |
Support Windows 7/ Windows 8/Windows 10/Windows 11/MAC OS |
| Cloud Support |
Yes |
| Smart Phone |
iPhone, iPad, Android, Android Pad |
| POE |
N/A |
| WIFI |
N/A |
| Storage |
| Interface Type |
2 SATA Hard Disk Interface (3.5" SATA) |
| Capacity |
Up to 10 TB capacity for each HDD |
| eSATA |
N/A |
| General |
| Language UI |
Simplified Chinese,Traditional Chinese, English, Polski,Russian,Deutsch, French, Portuguese, Spanish, Italian, Korean, Janpanese,Ukrainian |
| USB Interface |
Front panel: 1 × USB 2.0; Rear panel: 1 × USB 3.0 |
| RS485 |
N/A |
| Power consumption |
DC12V/4A ≤15W (Without Hard Disk) |
| Working Environment |
-10℃～50℃, 10%～90%(humidity) |
| Dimension(W×D×H) |
380 x 316 x 51mm |
| Weight |
2.71kg≤ kg(without HDD) |
