| System |
| Main Processor |
ARM Cortex A7 Processor |
| Operating System |
Embedded LINUX |
| Video |
| Input |
16CH(3840*2160,2592x1944, 2048x1536, 1920×1080, 1280×960, 1280×720, etc) |
| Output |
1 VGA, 1 HD |
| Audio |
| Input |
1 Port RCA |
| Output |
1 Port RCA(Linear, 1kΩ) |
| Audio Bit Rate |
64kbps |
| Audio Compression standard |
G711u, G711a, ADPCM_DVI4 |
| Intercom |
support (two-way) |
| Alarm |
| Sensor Input |
N/A |
| Output |
N/A |
| Motion Detection |
16 Channel, MD Zones: 396 (22 × 18) |
| Trigger Events |
Recording, Email, FTP, Snapshot, Buzzer and Screen Tips |
| Display |
| HD Output1 |
1024x768/60Hz，1280x720/60Hz，1280x1024/60Hz，1920x1080/60Hz，4K(3840x2160)/30Hz |
| HD Output2 |
N/A |
| VGA |
Resolution:1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| Display Split |
16CH/13CH/10CH/9CH/8CH/6CH/4CH/1CH |
| Digital Zoom |
YES |
| OSD |
Camera Title, Time, Recording, Motion Detection, Event Alarm |
| Recording |
| Video Compression |
H265/H264/H265+/H264+ |
| Resolution |
4k(3840×2160),5MP(2592×1944),4MP(2688×1520/2560×1440),3MP(2048×1536), 1080P(1920×1080), 960P(1280x960), 720P(1280×720),D1 (720×576/720×480) |
| Record Rate |
PAL :4K@10CHx25fps,5MP@16CH×25fp,4MP@16CHx25fp,3MP@16CH×25fp,1080P@16CH×25fp, 960P@16CH×25fp,720P@16CH×25fp, D1@16CH×25fp
NTSC: 4K@10CHx30fps,5MP@16CH×30fp,4MP@16CH×30fp,3MP@16CH×30fp,1080P@16CH×30fp, 960P@16CH×30fp, 720P@16CH×30fp, D1@16CH×30fp |
| Record Mode |
Manual\Timer\Motion Detection\Smart Event |
| Playback & Backup |
| Local Sync Playback |
1CH 4K@30fps, 1CH 5MP@30fps,2CH 4MP@30fps, 2CH 3M@30fps, 4CH 1080P@30fps, 4CH 960P@30fps, 4CH 720P@30fps, 16CH D1@30fps |
| Decode Capability |
4CH 1080P(1920x1080)@30fps |
| Remote Sync Playback |
YES |
| Search Mode |
ALL, Timing Video, Motion Detection, Tag search,Smart Event,Pictrue,Log |
| Playback Functions |
Play, pause, fast forward, rewind, previous frame, next frame, electronic zoom, clip, audio |
| Backup Mode |
USB Device/Network |
| Network |
| Interface |
1xRJ45 10M/100M/1000M Adaptive Ethernet Interface |
| Incoming Bandwidth |
100MB |
| Network Functions |
IPv6/TCP/IP, HTTP,HTTPS, UPnP, DNS, NTP, SMTP, DHCP, FTP, DDNS, RTSP, RTCP, p2p,PPPOE |
| Onvif |
onvif S,onvif T |
| Web Browser |
Edge,IE8-11, Google Chrome , Firefox ,Safari |
| CMS Software |
Support Windows 7/ Windows 8/Windows 10/MAC OS |
| Cloud Support |
Yes |
| Smart Phone |
iPhone, iPad, Android, Android Pad |
| POE |
N/A |
| WIFI |
N/A |
| Storage |
| Interface Type |
1 SATA Hard Disk Interface (3.5" SATA) |
| Capacity |
Up to 8TB capacity |
| eSATA |
N/A |
| General |
| Language UI |
Traditional Chinese, Simplified Chinese, English, Polish, Czech, Russian, Thai, Hebrew, Arabic, Bulgarian,German, French, Portuguese, Turkic, Spanish, Italian, Hungarian, Romanian, Korean, Dutch, Greek, Vietnamese,Janpanese |
| USB Interface |
2 USB 2.0 Interfaces |
| RS485 |
N/A |
| Power consumption |
DC12V 2A ≤20W (Without Hard Disk) |
| Working Environment |
-10~55℃/10~90% |
| Dimension(W×D×H) |
260*215*43(mm) |
| Weight |
2kg(without HDD) |
