| System |
| Main Processor |
MC6630 |
| Operating System |
Embedded LINUX |
| Video |
| Input |
Normal Mode:
Default: 4*(AHD/TVI/CVI:8M;AHD/TVI:5M,AHD/TVI/CVI:4MP/3MP/2MP/720P/960H)+2*IPC(Max5MP)
Analog+Network: 2*(AHD/TVI/CVI:8M;AHD/TVI:5M,AHD/TVI/CVI:4MP/3MP/2MP/720P/960H)+7*IPC(MAX 5MP)
Lite Mode:
Default: 4*(TVI/AHD/CVI: 5M@12fps; AHD/TVI/CVI: 4M@15fps; AHD/TVI/CVI: 3M@18fps; AHD/TVI/CVI: 1080P/720P; Analog: 960H)+2*network(MAX 5MP)
Analog+Network: 2*Analog(TVI/AHD/CVI: 5M@12fps; AHD/TVI/CVI: 4M@15fps; AHD/TVI/CVI: 3M@18fps; AHD/TVI/CVI: 1080P/720P; Analog: 960H)+7*network(MAX 5MP)
Network: 16*5MP/4MP/3MP/1080P/960P/720P(Total incoming bandwidth ≤48M) |
| Input |
4CH BNC |
| Signal Type |
Analog/AHD/CVI/TVI 2.0/TVI 3.0/Network |
| Output |
1HD,1 VGA, 1 CVBS |
| Audio |
| Input |
2 Channel, RCA , support AOC |
| Two-way Audio |
NO |
| Output |
1 Channel, RCA |
| Alarm |
| Sensor Input |
4 CH |
| Output |
1 CH |
| Motion Detection |
4 Channel(max 16 Channel in pure network mode) |
| Trigger Events |
Recording, Email, Screen tips, Buzzer, Push notifications(motion detection) |
| Email Alarm |
Send Image to The Designated E-mail |
| AI Function |
| Human Detection |
YES |
| PTZ |
| Interface |
RS485 |
| Protocol |
Pelco-D, Pelco-P |
| Baud Rate |
110~921600 |
| Address |
0~255 |
| Display |
| VGA |
Resolution: 1920 × 1080P/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz,1024 × 768/60Hz |
| HD Output |
Resolution: 1920 × 1080P/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz,1024 × 768/60Hz |
| Display Split |
16 Channel/9 Channel/4 Channel / 1Channel |
| Privacy Masking |
3 Rectangular Zones (Each camera) |
| OSD |
Camera title, Time, Video loss, Alarm, Motion detection, Recording |
| Recording |
| Video Compression |
H.265/H.265+/H.264/H.264+ |
| Audio Compression |
G.711U/G.711A |
| Resolution |
5MP(2592×1944),8MP_LITE(1920×2160),5MP_HALF(1296×1944),4MP(2560×1440),4MP_HALF(1280×1440), 3MP(2048×1536),3MP_Lite(1024×1536),1080P(1920×1080), 720P(1280×720), 960H(960×480) |
| Video Quality |
Lowest/Low/Ordinary/Good/Better/Best |
| Record Rate |
Normal Mode:
Analog: PAL:8MP_LITE(1920×2160 4*8fps), 5MP(2592×1944 4*6fps), 5MP_HALF(1296×1944 4*10fps),4MP(2560×1440 4*8fps),4MP_HALF(1280×1440 4*15fps),3MP(2048×1536 4*9fps),3MP_Lite(1024×1536 4*18fps), 1080P(1920x1080 4*15fps),720P(1280×720 4*25fps), 960H(960x480 4*25fps)
NTSC:8MP_LITE(1920×2160 4*8fps), 5MP(2592×1944 4*6fps),5MP_HALF(1296×1944 4*10fps),
4MP(2560×1440 4*8fps),4MP_HALF(1280×1440 4*15fps),3MP(2048×1536 4*9fps),3MP_Lite(1024×1536 4*18fps), 1080P(1920x1080 4*15fps),720P(1280×720 4*25fps), 960H(960×480 4*25fps)
Lite Mode:
PAL:5MP_Lite(1296×1944 4*10fps),4MP_Lite(1280×1440 4*15fps),3MP_Lite(1024×1536 4*18fps),1080N(960x1080 4*25fps),720P(1280×720 4*25fps), 960H(960×480 4*25fps)
NTSC: 5MP_Lite(1296×1944 4*10fps),4MP_Lite(1280×1440 4*15fps),3MP_Lite(1024×1536 4*18fps),1080N(960x1080 4*25fps),720P(1280×720 4*25fps), 960H(960×480 4*30fps)
Pure IP(H.265):
PAL: 5MP@8×25fps,4MP@12x25fps,3MP@12×25fps,1080P@16×25fps,960P@16×25fps,720P@16×25fps, D1@16×25fps
NTSC: 5MP@8×30fps,4MP@12×30fps,3MP@12×30fps,1080P@16×30fps, 960P@16×30fps,
720P@16×30fps, D1@16×30fps |
| Record Mode |
Manual\Timer\Motion Detection\Alarm Input\Intelligent |
| Playback & Backup |
| Decode Capability |
2CH 1080P@30fps |
| Sync Playback |
Normal Mode:
Pure Analog: 4CH 5M@6fps, 3CH 8M_Lite@8fps, 4CH 4M@8fps, 4CH 3M@9fps, 3CH 1080p@15fps
Mix Mode: 1CH 5M@30fps, 1CH 4M@30fps, 1CH 3M@30fps, 2CH 1080P@30fps
Pure IPC: 1CH 5MP@30fps, 1CH 4MP@30fps, 1CH 3M@30fps, 2CH 1080P@30fps
Lite Mode:
Pure Analog:4CH 5M_LITE@10fps,CH 4M_LITE@15fps,3M_LITE@18fps,4CH 1080N@25fps
Mix Mode: 1CH 5M@30fps, 1CH 4M@30fps, 1CH 3M@30fps, 2CH 1080P@30fps
Pure IPC: 1CH 5MP@30fps, 1CH 4MP@30fps, 1CH 3M@30fps, 2CH 1080P@30fps |
| Remote Playback |
4 Channel / 1Channel |
| Search Mode |
ALL, Channel, Manual, Time, Date, Motion Detection |
| Playback Functions |
Play, Pause, Stop, Fast play, Slow play, Rewind, Single frame forward/back, Digital Zoom, Full screen |
| Smart Phone Playback |
4 Channel |
| Backup Mode |
USB Device(with fomat FAT 32 )/Network/FTP |
| Network |
| Interface |
1 RJ45 10M/100M Adaptive Ethernet Interface |
| Network Functions |
TCP/IP, HTTP, UPnP, DNS, NTP, SMTP, DHCP, FTP, DDNS, RTP, RTSP, RTCP |
| DDNS |
Dyndns, changeip, no-ip, Oray, A-PRESS, MYQSEE, SKDDNS, SMART-EYES, ZEBEYE,HDPROVN |
| Web Browser |
Edge,IE8-11, Google Chrome , Firefox ,Safari |
| CMS Software |
Support Windows 7/ Windows 8/Windows 10/Windows 11/MAC OS |
| Extra Stream |
CIF/D1(1-30fps) |
| Smart Phone |
iPhone, ipad, Android ,Android pad |
| Hard Disk Driver |
| Interface Type |
1 SATA Interface |
| Capacity |
1 SATA Hard Disk (2.5"/3.5" SATA, Up to 8TB) |
| General |
| Language |
Simplified Chinese,Traditional Chinese, English, Polish, Czech, Russian, Thai, Hebrew, Arabic, Bulgarian,
Japanese, German, French, Portuguese, Turkic, Spanish, Italian, Hungarian, Romanian, korean, Dutch,
Greek, Vietnamese,
|
| UTC Control |
YES |
| USB Interface |
2 USB 2.0 Interfaces |
| Power consumption |
DC 12V/2A ≤20W (Without Hard Disk) |
| Working Environment |
-10~55℃/10~90% |
| Dimension (W×D×H) |
260*215*43(mm) |
| Weight |
2kg (Without HDD) |
