Zones
|
64 total inputs freely manageable in wireless/wired/ULTRABUS configuration.
The wireless zones are available on board and/or through RIVERRF or GATEWAY2K via ULTRABUS.
On-board 8 wired zones or 16 with split function (reducing the wireless zones). Expandable up to 64 by using RIVER concentrators via ULTRABUS
On board zones can be configured as radio zones or NO, NC, balanced, split, extended split, triple balanced.
|
|
ULTRABUS interface
|
1 x ULTRABUS (RS485 serial bus) for compatible devices connection
|
|
Outputs
|
Total 64 programmable outputs.
Connector with 8 outputs for ETRREL modules.
12V fuse-protected power output for detectors.
Alarm relay output with C-NO-NC free from potential contacts with 3A at AC24V capacity. It can be configured.
|
|
Areas/sectors
|
Management of 4 areas with 4 sectors each, or 2 areas with 8 sectors each, or 1 area with 16 sectors.
|
|
Users
|
32 max
|
|
Control devices
|
16 control devices over ULTRABUS
|
|
User interface
|
B/W LCD display, 128x65, with RGB backlight depending on operating conditions (adjustable)
Backlit 20-rubber-key keypad
Low-consumption proximity key reader (selectable), located among the sectors keys
|
|
Wireless module
|
3 channels settable via browser for digital transmissions on the 868.120 MHz, 868.820 MHz and 869.525 MHz frequencies for LPD devices.
|
|
Operative range
|
From 400 m to 2000 m in free space.
|
|
Events log
|
Historical memory with 1000 events capacity.
|
|
Connectors
|
MINIDIN for programming and remote control, CP8/SER2 cable required.
MINIUSB for programming, remote control and firmware update in simplified mode.
Support of ETREIB interface via CP8/SER2 cable for Konnex systems connections.
Connector for remote I66 proximity key readers.
|
|
Phone dialler
|
Telephone number list, 16 numbers for voice calls, 2 for digital calls, 4 for remote assistance, 1 for direct dial-out
|
|
Voice synthesis
|
Voice synthesis module with 64 messages that can be recorded by the installer using microphone and speaker
|
|
GSM
|
Optional GSM/GPRS module (MDGSMI or MDGSME) for connection to and from the control unit via GSM.
Connection to the e-Connect platform.
Voice transmission and digital transmission with ContactID, Fast Format and SIA IP Reporting (TCP-2007) protocols.
|
|
LAN
|
MDLAN Ethernet module (optional) for remote control and programming via TCP/IP.
Connection to the e-Connect platform.
Digital transmission with SIA IP Reporting (TCP-2007) protocol
|
|
Wi-Fi
|
MDWIFI Wi-Fi module (optional) for the connection to the e-Connect system
Digital transmission with SIA IP Reporting (TCP-2007) protocol
|
|
Functions
|
Compatible with wireless NG-TRX devices and devices of the first Villeggio generation
Control of up to 15 sirens and 15 configurable actuators.
Built-in temperature sensor with thermostat function. Wireless temperature sensor MDTEMP (optional).
Daily/weekly chronothermostat function with boiler block detection.
|
|
Built-in siren
|
Low-consumption built-in piezo siren
|
|
Case
|
White plastic housing protected against opening and removal
|
|
Battery
|
Battery PACK 1 supplied
|
|
Operating temperature
|
From +5 to +40 °C
|
|
Dimensions/weight
|
W 268 x H 210 x D 63 mm, 990 g with wall fixing bracket
|
|
Current draw
|
35 mA when armed, 27 mA when disarmed
|
|
Power supply
|
From mains 110-240Vac 50Hz (MDPOWER module included).
|
|
Certification
|
Certified IMQ-Allarme EN50131-3 grade 2, environmental class II, EN50131-5-3, EN50131-6 and EN50131-10
|
